久保田零件查询L10302 FRONT GRILLE SUPPORT [HST TYPE] HOOD/BONNETEPC Kubota online
广数供应链运营团队, 16 02月, 2025，浏览：
532 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
TA22040010
|
[1] |
SUPPORT FRONT
|
9.6800(lbs); 4.400
|
| 010. |
TA22040016
|
[1] |
SUPPORT FRONT
|
9.6800(lbs); 4.400
|
| 020. |
0112350820
|
[2] |
BOLT
|
0.0242(lbs); 0.011
|
| 020. |
0175450820
|
[2] |
BOLT FLANGE
|
0.0330(lbs); 0.015
|
| 040. |
TA04040024
|
[1] |
SHUTTER
|
0.5500(lbs); 0.250
|
| 050. |
TA04040033
|
[2] |
SPRING
|
0.0110(lbs); 0.005
|
| 060. |
TA04014213
|
[1] |
SUPPORT
|
2.8600(lbs); 1.300
|
| 070. |
0112350820
|
[4] |
BOLT
|
0.0242(lbs); 0.011
|
