卡特零件查询（AP-1055E） 341-0007: GENERATOR & MTG GP-HYDRAULIC
广数供应链运营团队, 16 02月, 2025，浏览：
945 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 7V-5628 | [2] | PLATE(TOP) | |
| 2. | 8X-6645 | [1] | STRAP AS-GROUND | |
| 3. | 228-4798 | [1] | FILM-IDENTIFICATION(GROUND) | |
| 5. | 310-8550 | [1] | PLATE | |
| 6. | 322-7953B | [1] | FILM-IDENTIFICATION(CIRCUIT BREAKER) | |
| 7. | 344-9355 | [1] | COVER AS | |
| 8. | 345-0212 | [1] | PLATE | |
| 9. | 348-2003 | [1] | WIRE AS-GROUND | |
| 10. | 349-1515B | [1] | FILM-IDENTIFICATION(CIRCUIT BREAKER) | |
| 11. | 367-6889 | [1] | WIRE AS-GROUND | |
| 12. | 387-1428 | [1] | FLASHING | |
| 13. | 397-8168 | [1] | GENERATOR GP-HYDRAULIC | |
| 14. | 398-8389 | [1] | STUD | |
| 15. | 099-2374M | [2] | BOLT-SOCKET HEAD(M5X0.8X12-MM) | |
| 16. | 3J-4818 | [1] | LOCKWASHER(EXTERNAL TOOTH) | |
| 17. | 4D-1326 | [2] | LOCKWASHER | |
| 18. | 5C-2874M | [2] | NUT(M5X0.8-THD) | |
| 19. | 5C-2890M | [3] | NUT(M6X1-THD) | |
| 20. | 5C-9553M | [3] | BOLT(M6X1X16-MM) | |
| 21. | 5P-1076 | [4] | WASHER-HARD(13.5X30X4-MM THK) | |
| 22. | 6V-8801 | [2] | NUT(3/8-16-THD) | |
| 23. | 7F-6998 | [2] | LOCKWASHER | |
| 24. | 7K-1181 | [3] | STRAP-CABLE | |
| 25. | 7P-1695 | [4] | WASHER(10.5X19X3-MM THK) | |
| 26. | 7R-7908 | [2] | CLAMP | |
| 27. | 7X-2534M | [2] | BOLT(M6X1X50-MM) | |
| 28. | 7X-7729 | [2] | WASHER(11X25X3-MM THK) | |
| 29. | 8T-4121 | [5] | WASHER-HARD(11X21X2.5-MM THK) | |
| 30. | 8T-4133M | [3] | NUT(M10X1.5-THD) | |
| 31. | 8T-4137M | [6] | BOLT(M10X1.5X20-MM) | |
| 32. | 8T-4139M | [4] | BOLT(M12X1.75X30-MM) | |
| 33. | 8T-4194M | [6] | BOLT(M12X1.75X50-MM) | |
| 34. | 8T-4195M | [1] | BOLT(M10X1.5X30-MM) | |
| 35. | 8T-4205 | [3] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 36. | 8T-4223 | [7] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 37. | 8T-4244M | [1] | NUT(M12X1.75-THD) | |
| 38. | 8T-4896 | [2] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 39. | 8T-7353M | [1] | BOLT-HIGH TEMPERATURE(M10X1.5X35-MM) | |
| 40. | 145-5664E | | SEAL(35-CM) | |
| 41. | 445-7531 | [1] | WIRE AS-GROUND | |
| 42. | 8T-4138M | [1] | BOLT(M6X1X20-MM) | |
| 43. | 1H-3338 | [1] | LOCKWASHER(EXTERNAL TOOTH) | |
| 44. | 1A-8912 | [2] | WASHER(6.7X12.7X1.6-MM THK) | |
| | B | | USE AS REQUIRED |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
