卡特零件查询（AP-1055E） 321-2435: GUARD GP-VANDALISM
广数供应链运营团队, 16 02月, 2025，浏览：
453 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 246-2641 | [1] | PADLOCK GP | |
| | 5P-8500 | [1] | KEY | |
| 2. | 107-5014 | [2] | KNOB | |
| 3. | 214-7536 | [2] | SPACER(8.3X10.8X6-MM THK) | |
| 4. | 281-7228 | [1] | PLATE | |
| 5. | 332-6897 | [1] | COVER | |
| 6. | 137-3626M | [2] | BOLT-SPECIAL(M6X1X23.25-MM) | |
| 7. | 150-1293M | [2] | SCREW-BUTTON HEAD(M4X0.7X12-MM) | |
| 8. | 4B-4863 | [2] | WASHER(4.7X11X1.2-MM THK) | |
| 9. | 5C-2890M | [2] | NUT(M6X1-THD) | |
| 10. | 5C-8312M | [2] | NUT(M4X0.7-THD) | |
| 11. | 5P-4116 | [4] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 12. | 9X-8256 | [2] | WASHER(6.6X12X2-MM THK) | |
| | M | | METRIC PART |
