久保田零件查询T03200 SEAT HOOD(BONNET)/ROPSEPC Kubota online
广数供应链运营团队, 16 02月, 2025，浏览：
800 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
3511085010
|
[1] |
ASSY SEAT
|
0.0000(lbs); 0.000
|
| 005. |
3511018400
|
[1] |
ASSY SUSPENSION SEAT
|
9.4600(lbs); 4.300
|
| 008. |
3525818430
|
[1] |
ARM 1
|
1.4740(lbs); 0.670
|
| 010. |
3411918450
|
[2] |
SPRING SEAT
|
0.2574(lbs); 0.117
|
| 011. |
3525818460
|
[1] |
BOLT ADJUSTING
|
0.1760(lbs); 0.080
|
| 012. |
3426918490
|
[4] |
PIN
|
0.1320(lbs); 0.060
|
| 013. |
0211850100
|
[1] |
NUT
|
0.0110(lbs); 0.005
|
| 014. |
0211650100
|
[1] |
NUT
|
0.0088(lbs); 0.004
|
| 015. |
0401350100
|
[8] |
WASHER PLAIN
|
0.0088(lbs); 0.004
|
| 016. |
0551150220
|
[8] |
PIN SPLIT
|
0.0022(lbs); 0.001
|
| 017. |
3216018440
|
[1] |
CUSHION
|
0.0286(lbs); 0.013
|
| 018. |
3525818480
|
[2] |
ROLLER
|
0.0110(lbs); 0.005
|
| 019. |
3216018440
|
[2] |
CUSHION
|
0.0286(lbs); 0.013
|
| 020. |
0113051020
|
[6] |
BOLT
|
0.0000(lbs); 0.000
|
| 021. |
0113051038
|
[2] |
BOLT
|
0.0000(lbs); 0.000
|
| 022. |
3530018460
|
[1] |
SEAT SPACER FRONT
|
0.8140(lbs); 0.370
|
| 023. |
3530018470
|
[1] |
SEAT SPACER REAR
|
1.1660(lbs); 0.530
|
| 024. |
3511018470
|
[2] |
BOLT
|
0.0264(lbs); 0.012
|
| 025. |
0211450080
|
[2] |
NUT
|
0.0110(lbs); 0.005
|
| 026. |
3534018510
|
[1] |
ASSY BOX TOOLS
|
6.7100(lbs); 3.050
|
| 027. |
3534018520
|
[1] |
BOX TOOLS
|
3.3000(lbs); 1.500
|
| 028. |
6657154520
|
[1] |
CAP SID
|
0.1870(lbs); 0.085
|
| 029. |
0105350614
|
[2] |
BOLT
|
0.0110(lbs); 0.005
|
| 030. |
0451250060
|
[2] |
WASHER SPRING
|
0.0022(lbs); 0.001
|
| 031. |
0117351225
|
[2] |
BOLT
|
0.0726(lbs); 0.033
|
| 032. |
0451250120
|
[2] |
WASHER SPRING
|
0.0066(lbs); 0.003
|
