卡特零件查询（BG1055E） 375-7822: WINDOW GP-FRONT
广数供应链运营团队, 16 02月, 2025，浏览：
600 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 6V-6543 | [2] | BLADE AS-WIPER(503-MM) | |
| 2. | 8T-2444 | [4] | STUD-BALL | |
| 3. | 8Y-6377 | [2] | STRIKER | |
| 4. | 112-5344 | [1] | LATCH AS-DOOR(LH) | |
| 5. | 112-5345 | [1] | LATCH AS-DOOR(RH) | |
| 6. | 283-4738Y | [1] | MOTOR GP-WINDOW WIPER(RH) | |
| 7. | 283-4739Y | [1] | MOTOR GP-WINDOW WIPER(LH) | |
| 8. | 292-0618 | [2] | KNOB | |
| 9. | 367-6278 | [2] | BRACKET | |
| 10. | 367-6279 | [2] | BRACKET | |
| 11. | 370-4159Y | [1] | WINDOW GP(FRONT) | |
| 12. | 370-6304 | [2] | WINDOW | |
| 13. | 370-6305 | [1] | FRAME-WINDOW(RH) | |
| 14. | 370-6306 | [1] | FRAME-WINDOW(LH) | |
| 15. | 370-7288 | [2] | ARM AS-WINDOW WIPER(DRY) | |
| 16. | 382-4595 | [2] | SPRING-GAS(ROD END) | |
| 17. | 5C-2890M | [8] | NUT(M6X1-THD) | |
| 18. | 5C-7261M | [26] | NUT(M8X1.25-THD) | |
| 19. | 5P-4116 | [44] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 20. | 5S-7379 | [2] | BOLT(3/8-16X0.875-IN) | |
| 21. | 7X-2533M | [8] | BOLT(M6X1X35-MM) | |
| 22. | 7X-7729 | [12] | WASHER(11X25X3-MM THK) | |
| 23. | 8T-4121 | [12] | WASHER-HARD(11X21X2.5-MM THK) | |
| 24. | 8T-4133M | [12] | NUT(M10X1.5-THD) | |
| 25. | 8T-4136M | [12] | BOLT(M10X1.5X25-MM) | |
| 26. | 8T-4189M | [22] | BOLT(M8X1.25X20-MM) | |
| 27. | 8T-4224 | [4] | WASHER-HARD(8.8X16X2-MM THK) | |
| 28. | 8T-4896 | [2] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 29. | 9X-8256 | [16] | WASHER(6.6X12X2-MM THK) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
