卡特零件查询（BG1055E） 378-6613: PLANETARY GP-AUGER
广数供应链运营团队, 16 02月, 2025，浏览：
383 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8T-0342M | [10] | BOLT-SOCKET HEAD(M10X1.5X80-MM) | |
| 2. | 146-4263 | [2] | SEAL-O-RING | |
| 3. | 361-3946 | [1] | KIT-GEAR(INPUT) | |
| | | | (INCLUDES RETAINING RING, SUN GEAR, REDUCTION GEARS, SPACER & RING GEAR) |
| 4. | 361-3945 | [1] | KIT-HOUSING(OUTPUT) | |
| | | | (INCLUDES NUT, SPACER, BEARING AS, SEAL, BREATHER, TAPER BEARING, DUST CAP, SPACER, SHAFT, WASHERS & PLUGS) |
| 5. | 144-9773 | [4] | WASHER | |
| 6. | 371-2175 | [1] | BREATHER | |
| 7. | 371-2032 | [1] | SPACER(55X72X5.8-MM THK) | |
| 8. | 371-1923 | [1] | CAP-DUST | |
| 9. | 376-6648 | [1] | BEARING-TAPERED ROLLER | |
| 10. | 371-2033 | [2] | PLUG | |
| 11. | 371-2034 | [1] | PLUG-MAGNETIC | |
| 12. | 396-8318 | [1] | SEAL-LIP TYPE | |
| 13. | 298-6953 | [1] | BEARING AS | |
| 14. | 368-8584 | [1] | SPACER(42.5X49.5X3.5-MM THK) | |
| 15. | 368-8490 | [1] | NUT-SPANNER | |
| 16. | 362-1295 | [1] | SPACER(40X47X14.5-MM THK) | |
| 17. | 8U-2382 | [1] | RING-RETAINING(1-MM THK) | |
| 18. | 514-5255 | [1] | GEAR-SUN | |
| | M | | METRIC PART |
