| 1. | 7V-5628 | [2] | PLATE(TOP) | |
| 2. | 143-9644 | [2] | PLATE-RETAINER | |
| 3. | 177-2215 | [4] | STRAP-DUAL CLAMP | |
| 4. | 200-6345 | [4] | SADDLE-MOUNTING(DUAL SWIVEL) | |
| 5. | 204-2281 | [8] | STRAP-CABLE | |
| 7. | 256-6454 | [1] | SENSOR-TEMPERATURE(2-PIN)(AIR CONDITIONER) | |
| 8. | 288-6913 | [1] | BRACKET AS | |
| 9. | 347-4044 | [1] | BRACKET AS | |
| 10. | 348-6675 | [1] | PLATE AS | |
| 11. | 382-4382 | [1] | HARNESS AS-CHASSIS | |
| | 126-1774 | [1] | COVER-CONNECTOR | |
| | 9X-3401 | [68] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 127-5485 | [1] | PLUG AS-CONNECTOR(1-PIN) | |
| | 160-7689 | [1] | PLUG AS-CONNECTOR(70-PIN) | |
| | 159-9322 | [1] | SEAL-O-RING | |
| | 155-2270 | [18] | KIT-CONNECTING PLUG(2-PIN) | |
| | 174-0503 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 230-4011 | [3] | PLUG AS-CONNECTOR(2-PIN) | |
| | | | (EACH INCLUDES) |
| | 264-7029 | [1] | SEAL-CONNECTOR | |
| | 225-3854 | [1] | PLUG AS-CONNECTOR(31-PIN) | |
| | 8T-8737 | [79] | PLUG-SEAL | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 103-0213 | [1] | RECEPTACLE AS-CONNECTOR(70-PIN) | |
| | 134-2540 | [1] | RECEPTACLE AS-CONNECTOR | |
| | 225-3861 | [1] | RECEPTACLE AS-CONNECTOR(31-PIN) | |
| | 180-9340 | [100] | SOCKET-CONNECTOR(14-GA TO 18-GA) | |
| | 8N-1543 | [1] | SOCKET-CONNECTOR(10-GA) | |
| | 9X-6772 | [2] | STRAP-CABLE | |
| | 131-1488 | [1] | TERMINAL AS-RING(6-GA TO 8-GA) | |
| | 6H-3586 | [1] | TERMINAL-RING(6-GA TO 8-GA, 1/4-IN SCREW) | |
| | 119-3662E | | TUBE-HEAT SHRINK(10.85-MM DIA)(4-CM) | |
| | 131-1492 | [2] | TERMINAL AS-RING(6-GA TO 8-GA) | |
| | | | (EACH INCLUDES) |
| | 3K-4528 | [1] | TERMINAL-RING(6-GA TO 8-GA, 1/2-IN SCREW) | |
| | 119-3662E | | TUBE-HEAT SHRINK(10.85-MM DIA)(4-CM) | |
| | 2L-8071 | [1] | TERMINAL-RING(10-GA TO 12-GA, 1/2-IN SCREW) | |
| | 7N-9017 | [1] | TERMINAL-RING(18-GA TO 22-GA, NO. 10 SCREW) | |
| | 125-7874E | [1] | TUBE-HEAT SHRINK(5.72-MM DIA)(35-CM) | |
| 12. | 360-1738 | [1] | PLATE | |
| 13. | 096-6166 | [2] | WASHER-HARD(4.5X9X1-MM THK) | |
| 14. | 130-5300 | [1] | CLIP | |
| 15. | 130-5301 | [5] | CLIP | |
| 16. | 132-5789 | [5] | CLIP(LADDER) | |
| 17. | 139-0428 | [4] | CLAMP | |
| 18. | 144-8976 | [1] | SPACER(11X25.4X26-MM THK) | |
| 19. | 211-0052 | [1] | NUT(1-11/16-18-THD) | |
| 20. | 327-0325 | [1] | STRAP-CABLE | |
| 21. | 4P-7428 | [1] | CLIP(LADDER) | |
| 22. | 4P-7429 | [2] | CLIP(LADDER) | |
| 23. | 4P-7581 | [6] | CLIP(LADDER) | |
| 24. | 4P-7582 | [2] | CLIP | |
| 25. | 5C-9553M | [2] | BOLT(M6X1X16-MM) | |
| 26. | 6V-7743M | [1] | LOCKNUT(M6X1-THD) | |
| 27. | 6V-9672M | [2] | SCREW-MACHINE(M4X0.7X16-MM) | |
| 28. | 7K-1181 | [27] | STRAP-CABLE | |
| 29. | 7V-5626 | [4] | CLAMP | |
| 30. | 8C-8451M | [4] | BOLT(M6X1X40-MM) | |
| 31. | 8T-4121 | [4] | WASHER-HARD(11X21X2.5-MM THK) | |
| 32. | 8T-4137M | [1] | BOLT(M10X1.5X20-MM) | |
| 33. | 8T-4179M | [2] | BOLT(M12X1.75X20-MM) | |
| 34. | 8T-4182M | [1] | BOLT(M10X1.5X45-MM) | |
| 35. | 8T-4191M | [2] | BOLT(M10X1.5X16-MM) | |
| 36. | 8T-4200M | [5] | BOLT(M8X1.25X16-MM) | |
| 37. | 8T-4205 | [2] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 38. | 8T-4223 | [3] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 39. | 8T-4224 | [6] | WASHER-HARD(8.8X16X2-MM THK) | |
| 40. | 8T-4244M | [1] | NUT(M12X1.75-THD) | |
| 41. | 8T-5391 | [1] | BOLT(5/16-18X0.5-IN) | |
| 42. | 8T-7524 | [1] | SEAL-O-RING | |
| 43. | 9X-2480M | [4] | BOLT(M6X1X45-MM) | |
| 44. | 9X-8256 | [1] | WASHER(6.6X12X2-MM THK) | |
| 45. | 7E-0976 | [1] | BOOT | |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
