卡特零件查询（BG1055E） 328-3509: ADJUSTER GP-HEIGHT
广数供应链运营团队, 16 02月, 2025，浏览：
828 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 1A-4168 | [8] | NUT(1-1/4-12-THD) | |
| 2. | 3B-8488 | [2] | FITTING-GREASE(1/8-27 PTF) | |
| 3. | 3B-8489 | [2] | FITTING-GREASE(1/8-27 PTF) | |
| 4. | 8I-0256 | [8] | BUSHING | |
| 5. | 8I-0267 | [4] | CAP | |
| 6. | 8I-0740 | [2] | COUPLING GP | |
| | | | (EACH INCLUDES) |
| | 4B-9806 | [1] | SETSCREW-SOCKET(1/4-20X0.25-IN) | |
| 7. | 102-2739 | [2] | KEY-SQUARE | |
| 8. | 106-6340 | [2] | SPACER(10.74X17.14X7-MM THK) | |
| 9. | 113-4339 | [4] | SPACER(10.5X18X21-MM THK) | |
| 10. | 165-4655 | [2] | BLOCK AS | |
| 11. | 165-4731 | [2] | PIN AS | |
| 12. | 185-5431 | [8] | BOLT-SPECIAL | |
| 13. | 196-2503Y | [2] | JACK GP-HEIGHT ADJUSTER | |
| 14. | 196-2564 | [1] | BRACKET AS | |
| 15. | 196-2566 | [4] | POINTER | |
| 16. | 198-2819 | [8] | RING-RETAINING | |
| 17. | 206-6630 | [1] | BRACKET AS | |
| 18. | 277-2006Y | [2] | MOTOR GP-POWER ADJUSTER | |
| 19. | 277-3180 | [2] | FILM-IDENTIFICATION(HEIGHT ADJUST) | |
| 20. | 277-3181 | [2] | FILM-IDENTIFICATION(SLOPE) | |
| 21. | 279-6482 | [4] | SPACER(38X21X20-MM THK) | |
| 23. | 334-3363 | [1] | FRAME AS(LH) | |
| 24. | 334-3365 | [1] | FRAME AS(RH) | |
| 25. | 334-3367 | [2] | PLATE AS | |
| 26. | 341-8407 | [8] | LOCK | |
| 27. | 354-6744 | [4] | TUBE AS | |
| 28. | 174-4883 | [2] | STUD(3/8-16X2-IN) | |
| 29. | 4L-6454 | [2] | BOLT(3/8-16X1-IN) | |
| 30. | 6V-8801 | [2] | NUT(3/8-16-THD) | |
| 31. | 7X-2566M | [2] | BOLT(M20X2.5X110-MM) | |
| 32. | 7X-7729 | [22] | WASHER(11X25X3-MM THK) | |
| 33. | 8T-4123 | [6] | WASHER(3.62X5.75X0.375-MM THK) | |
| 34. | 8T-4131M | [6] | NUT(M20X2.5-THD) | |
| 35. | 8T-4136M | [10] | BOLT(M10X1.5X25-MM) | |
| 36. | 8T-4183M | [8] | BOLT(M12X1.75X40-MM) | |
| 37. | 8T-4191M | [4] | BOLT(M10X1.5X16-MM) | |
| 38. | 8T-4196M | [4] | BOLT(M10X1.5X35-MM) | |
| 39. | 8T-4223 | [8] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 40. | 8T-4896 | [8] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 41. | 8T-5005M | [4] | BOLT(M10X1.5X70-MM) | |
| 42. | 8T-5460M | [4] | BOLT(M20X2.5X40-MM) | |
| 43. | 8T-5439 | [2] | WASHER-HARD(21.5X45X6-MM THK) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
