卡特零件查询（BG1055E） 276-4603: GATE GP-END
广数供应链运营团队, 16 02月, 2025，浏览：
975 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8I-0544 | [2] | BUSHING | |
| 2. | 102-2719 | [2] | LOCKNUT(2-1/4-16-THD) | |
| 3. | 247-7616 | [4] | ACTUATOR GP(END GATE) | |
| 4. | 254-6836 | [4] | SUPPORT AS | |
| 5. | 258-0735 | [4] | SPRING | |
| 6. | 263-0830 | [1] | PLATE AS(LH) | |
| 7. | 351-4475 | [2] | SHOE AS | |
| | | | (EACH INCLUDES) |
| | 112-9073M | [4] | STUD-WELD(M12X1.75X21.1-MM) | |
| 8. | 263-0837 | [1] | PLATE AS(RH) | |
| 9. | 276-4541 | [2] | SUPPORT AS | |
| 10. | 286-1650 | [1] | SUPPORT AS(RH) | |
| 11. | 286-1651 | [1] | SUPPORT AS(LH) | |
| 12. | 106-0547 | [2] | WASHER | |
| 13. | 5P-1076 | [8] | WASHER-HARD(13.5X30X4-MM THK) | |
| 14. | 6V-7676M | [4] | NUT(M24X3-THD) | |
| 15. | 7X-2489M | [4] | BOLT(M24X3X100-MM) | |
| 16. | 7X-7729 | [8] | WASHER(11X25X3-MM THK) | |
| 17. | 8T-0363M | [2] | BOLT(M24X3X120-MM) | |
| 18. | 8T-0389M | [4] | LOCKNUT(M10X1.5-THD) | |
| 19. | 8T-4121 | [8] | WASHER-HARD(11X21X2.5-MM THK) | |
| 20. | 8T-4133M | [4] | NUT(M10X1.5-THD) | |
| 21. | 8T-4137M | [8] | BOLT(M10X1.5X20-MM) | |
| 22. | 8T-4167 | [8] | WASHER-HARD(26X44X4-MM THK) | |
| 23. | 8T-4179M | [8] | BOLT(M12X1.75X20-MM) | |
| 24. | 8T-4183M | [4] | BOLT(M12X1.75X40-MM) | |
| 25. | 8T-4196M | [4] | BOLT(M10X1.5X35-MM) | |
| 26. | 8T-4223 | [16] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 27. | 8T-4244M | [20] | NUT(M12X1.75-THD) | |
| 28. | 8T-5412M | [8] | BOLT(M12X1.75X140-MM) | |
| 29. | 8T-6466M | [4] | BOLT(M10X1.5X60-MM) | |
| | M | | METRIC PART |
