卡特零件查询（AP-1055F） 473-3306: LINES GP-VIBRATORY
广数供应链运营团队, 16 02月, 2025，浏览：
573 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 6V-0852 | [1] | CAP-DUST | |
| 2. | 138-4572 | [2] | COVER | |
| 3. | 364-4568 | [2] | STRAP | |
| 4. | 364-4569 | [3] | STRAP | |
| 5. | 437-8887 | [2] | BLOCK | |
| 6. | 437-8890 | [2] | BLOCK | |
| 7. | 437-8891 | [2] | PLATE | |
| 8. | 442-2490 | [2] | BLOCK | |
| 9. | 442-2509M | [8] | SPACER(11.2X16X75.6-MM THK) | |
| 10. | 448-6987 | [2] | PLATE AS | |
| | | | (EACH INCLUDES) |
| | 102-8706 | [1] | PLATE AS | |
| 11. | 453-0258 | [8] | SPACER(17.6X24X30-MM THK) | |
| 12. | 461-7471 | [1] | SUPPORT AS | |
| 13. | 461-7474 | [1] | PLATE | |
| 14. | 461-7475 | [1] | PLATE AS | |
| | 8T-3490M | [2] | NUT-WELD(M10X1.5-THD) | |
| | 102-8706 | [1] | PLATE AS | |
| 15. | 461-7497 | [1] | PLATE AS | |
| | 8T-3490M | [2] | NUT-WELD(M10X1.5-THD) | |
| | 102-8706 | [1] | PLATE AS | |
| 16. | 464-3984I | [1] | HOSE AS | |
| 17. | 464-3985I | [1] | HOSE AS | |
| 18. | 464-3986I | [1] | HOSE AS | |
| 19. | 464-3987I | [1] | HOSE AS | |
| 20. | 464-3988I | [1] | HOSE AS | |
| 21. | 464-3989I | [1] | HOSE AS | |
| 22. | 464-3990I | [1] | HOSE AS | |
| 23. | 464-3991I | [1] | HOSE AS | |
| 24. | 464-3992I | [1] | HOSE AS | |
| 25. | 464-3993I | [1] | HOSE AS | |
| 26. | 464-3994I | [1] | HOSE AS | |
| 27. | 464-3995I | [1] | HOSE AS | |
| 28. | 464-3996I | [1] | HOSE AS | |
| 29. | 464-3997 | [1] | PLATE AS | |
| | 178-8505 | [1] | PLATE-WELD | |
| | 464-4090 | [1] | PLATE | |
| 30. | 464-3998 | [4] | BLOCK | |
| 31. | 464-3999 | [4] | BLOCK | |
| 32. | 473-2323 | [2] | BLOCK | |
| 33. | 473-2324 | [1] | PLATE | |
| 34. | 473-2325 | [1] | PLATE | |
| 35. | 487-7852 | [1] | SUPPORT AS | |
| 36. | 148-8376 | [1] | ELBOW AS | |
| | 6V-8983 | [1] | ELBOW | |
| | 6V-9746 | [2] | SEAL-O-RING | |
| 37. | 148-8430 | [1] | TEE AS | |
| | 6V-9746 | [1] | SEAL-O-RING | |
| | 7X-0873 | [1] | TEE | |
| 38. | 148-8455 | [2] | UNION AS | |
| | | | (EACH INCLUDES) |
| | 6V-8997 | [1] | UNION | |
| | 6V-9746 | [2] | SEAL-O-RING | |
| 39. | 164-5567 | [1] | COUPLER AS-QUICK DISCONNECT(MALE) | |
| | 6V-3965 | [1] | FITTING(QUICK DISCONNECT) | |
| | 214-7568 | [1] | SEAL-O-RING | |
| 40. | 165-4933 | [2] | ELBOW AS | |
| | | | (EACH INCLUDES) |
| | 6V-8990 | [1] | ELBOW | |
| | 6V-9746 | [2] | SEAL-O-RING | |
| 41. | 169-7404 | [1] | ELBOW AS | |
| | 6V-8982 | [1] | ELBOW | |
| | 7J-9108 | [2] | SEAL-O-RING | |
| 42. | 169-7409 | [2] | UNION AS | |
| | | | (EACH INCLUDES) |
| | 6V-8996 | [1] | UNION | |
| | 7J-9108 | [2] | SEAL-O-RING | |
| 43. | 190-9821 | [2] | ELBOW AS | |
| | | | (EACH INCLUDES) |
| | 6V-8989 | [1] | ELBOW | |
| | 7J-9108 | [2] | SEAL-O-RING | |
| 44. | 237-4257 | [4] | CLAMP-HALF | |
| 45. | 288-7158M | [8] | STUD(M10X1.5X125-MM) | |
| 46. | 2P-1293 | [5] | LOCKNUT(1-3/16-12-THD) | |
| 47. | 344-5675M | [16] | NUT(M10X1.5-THD) | |
| 48. | 6V-9170 | [5] | NUT-BULKHEAD(1-14-THD) | |
| 49. | 8T-4121 | [20] | WASHER-HARD(11X21X2.5-MM THK) | |
| 50. | 8T-4136M | [12] | BOLT(M10X1.5X25-MM) | |
| 51. | 8T-6912M | [2] | BOLT(M8X1.25X50-MM) | |
| 52. | 9X-2041M | [4] | SCREW-TRUSS HEAD(M10X1.5X20-MM) | |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
