卡特零件查询（AP-1055F） 396-7165: MOTOR GP-GEAR
广数供应链运营团队, 16 02月, 2025，浏览：
363 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 155-8353 | [1] | KEY | |
| 2. | 9S-1354 | [1] | NUT(5/8-18-THD) | |
| 3. | 199-2222 | [1] | WASHER(18.2X31X9.2-MM) | |
| 4. | 313-5646M | [4] | BOLT(M14X2X60-MM) | |
| 5. | 350-9186J | [1] | SEAL-DUST | |
| 6. | 6V-7723J | [1] | RING-RETAINING | |
| 7. | 378-9296 | [1] | WASHER-BACKUP | |
| 8. | 350-9190 | [1] | VALVE(ANTI-CAVITATION) | |
| 9. | 271-2360 | [4] | WASHER-HARD(15X22X2.5-MM THK) | |
| | | | |
| | | | PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE NUMBER ARE NOT SERVICED SEPARATELY |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 423-3512J | [1] | KIT-SEAL | |
| | | | (INCLUDES BUSHING, SHAFT SEALS, BACKUP SEALS, SEALS & PARTS MARKED "H" IN THE GRAPHIC) |
| | J | | KIT MARKED J SERVICES PART(S) MARKED J |
| | M | | METRIC PART |
