卡特零件查询（BG-225C） 115-2289: COVER GP-ENGINE & PLATFORM
广数供应链运营团队, 16 02月, 2025，浏览：
809 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | | [1] | PLATE |
| 2. | 5P-4116 | [4] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 3. | 8T-2502 | [8] | BOLT(3/8-16X1.125-IN) | |
| 4. | 117-1251 | [1] | PLATE | |
| 5. | 121-2942 | [1] | ANGLE | |
| 6. | 5P-2566 | [14] | BOLT(1/2-13X1.5-IN) | |
| 7. | 6V-8188 | [20] | NUT(1/2-13-THD) | |
| 8. | 8T-4223 | [12] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 9. | 163-0308 | [1] | PLATE AS(LH) | |
| | 7R-6214 | [2] | HINGE | |
| 10. | 127-8514 | [1] | PANEL AS | |
| | 7R-7963 | [1] | PLATE AS | |
| 11. | 5S-7382 | [3] | BOLT(3/8-16X1.375-IN) | |
| 12. | 8T-1579 | [2] | PLATE | |
| 13. | 8T-9496 | [4] | LOCKNUT(9/16-18-THD) | |
| 14. | 8Y-4000 | [2] | LATCH AS(T-BAR, COMPARTMENT) | |
| | | | (EACH INCLUDES) |
| | 6H-3956 | [1] | PIN | |
| | 7X-0766 | [1] | SPRING-LATCH | |
| | 8Y-3966 | [1] | WASHER(14.7X35X1.57-MM THK) | |
| | 8Y-3998 | [1] | HANDLE-LATCH | |
| | 8Y-3999 | [1] | BRACKET-MOUNTING | |
| | 8Y-8306 | [1] | SHAFT-LATCH | |
| 15. | 4L-6454 | [31] | BOLT(3/8-16X1-IN) | |
| 16. | 6V-8801 | [92] | NUT(3/8-16-THD) | |
| 17. | 5P-1075 | [118] | WASHER-HARD(10.2X22.5X3-MM THK) | |
| 18. | 5M-3062 | [11] | BOLT(3/8-16X0.75-IN) | |
| 19. | 8T-4012 | [4] | SCREW-HEX SOCKET(1/2-13X1.5-IN) | |
| 20. | 108-7849 | [1] | PLATE | |
| 21. | 166-4136 | [1] | PLATE AS | |
| 22. | 139-8425 | [1] | PLATE | |
| 23. | 6R-1941 | [1] | CONNECTOR | |
| 24. | 8T-4205 | [4] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 25. | 103-1900 | [2] | HINGE | |
| 26. | 137-8958 | [1] | PANEL AS | |
| 27. | 145-5134 | [1] | PANEL AS | |
| 28. | 145-5135 | [1] | PANEL AS | |
| 29. | 7X-2484 | [1] | LATCH-HANDLE | |
| 30. | 4M-5281 | [4] | BOLT(1/4-20X0.75-IN) | |
| 31. | 117-1137 | [1] | PANEL AS-SIDE | |
| | 7R-6214 | [2] | HINGE | |
| | 7F-7691 | [2] | CLIP-RACK STOP | |
| | 9W-8940 | [1] | PLATE | |
| 32. | 127-8515 | [1] | PANEL AS | |
| | 7R-7963 | [1] | PLATE AS | |
| 33. | 108-7756 | [4] | ROD | |
| 34. | 7R-9612 | [2] | ROD | |
| 35. | 2D-6235 | [4] | LOCKNUT(1/4-20-THD) | |
| 36. | 147-4526 | [1] | PANEL AS | |
| | 7X-2484 | [1] | LATCH-HANDLE | |
| 37. | 102-9503 | [1] | PANEL | |
| 38. | 102-9504 | [1] | PANEL | |
| 39. | 110-4156 | [2] | PANEL | |
| 40. | 103-1894 | [1] | PANEL AS | |
| 41. | 108-2152 | [1] | SUPPORT AS | |
| 42. | 148-2197 | [1] | BRACKET AS | |
| | 9G-9154 | [2] | CLIP | |
| | 5E-9146 | [2] | CHANNEL | |
| 43. | 030-7572 | [18] | BOLT(3/8-16-THD) | |
| 44. | 117-1135 | [1] | PANEL AS(LH) | |
| | 7X-2484 | [1] | LATCH-HANDLE | |
| 45. | 117-1133 | [1] | PANEL AS(RH) | |
| | 7X-2484 | [1] | LATCH-HANDLE | |
| 46. | 108-4426 | [1] | ANGLE | |
| 47. | 9G-9154 | [2] | CLIP | |
| 48. | 108-8330 | [1] | PANEL AS | |
| 49. | 108-8331 | [1] | PANEL AS | |
| 50. | 3B-4618 | [6] | PIN-COTTER | |
| 51. | 140-2244 | [1] | PLATE | |
| 52. | 103-1504 | [2] | ANGLE | |
| 53. | 6V-8189 | [2] | NUT(5/16-18-THD) | |
| 54. | 8T-8919 | [2] | BOLT(1/2-13X1.75-IN) | |
| 55. | 111-1777 | [12] | BUMPER-RUBBER | |
| 56. | 111-1778 | [4] | BUMPER-RUBBER | |
| 57. | 4L-9337 | [10] | BOLT(3/8-16X1.5-IN) | |
| 58. | 8T-9007BE | | SEAL | |
| 59. | 8T-4896 | [60] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 60. | 9B-7237 | [31] | BOLT(3/8-16X1.25-IN) | |
| 61. | 139-8426 | [1] | COVER | |
| 62. | 104-2231 | [2] | NUT-SPRING | |
| 63. | 139-8427 | [1] | COVER | |
| 64. | 139-8428 | [2] | PLATE | |
| 65. | 5P-2228 | [2] | BOLT(1/2-13X1-IN) | |
| 66. | 2R-0504 | [2] | NUT(5/16-18-THD) | |
| 67. | 7D-9708 | [4] | BOLT-SPECIAL | |
| 68. | 5P-1076 | [32] | WASHER-HARD(13.5X30X4-MM THK) | |
| | B | | USE AS REQUIRED |
| | E | | ORDER BY THE CENTIMETER |
