卡特零件查询（BG-225C） 115-2287: STRUCTURAL AR
广数供应链运营团队, 16 02月, 2025，浏览：
824 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 117-9516Y | [1] | ARM GP-TOW | |
| | 119-1765Y | [1] | BEAM GP-TRANSVERSE | |
| | 115-2289Y | [1] | COVER GP-ENGINE & PLATFORM | |
| | 115-2263Y | [1] | FRAME AS-MAIN | |
| | | | S/N 5GN1-500; 9DN1-504 |
| | 235-1801 | [1] | FRAME AS | |
| | | | S/N 5GN501-UP; 9DN505-UP |
| | 104-6579Y | [1] | GUIDE GP-STEERING | |
| | 115-2288Y | [1] | HOPPER GP | |
| | | | S/N 5GN1-473; 9DN1-383 |
| | 172-3961Y | [1] | HOPPER GP | |
| | | | S/N 5GN474-UP; 9DN384-UP |
| | 140-8379Y | [1] | PLATFORM GP | |
| | 121-6173Y | [1] | SUPPORT GP-TOW ARM | |
| | 142-2827Y | [1] | SUPPRESSION GP-SOUND | |
| | Y | | SEPARATE ILLUSTRATION |
