卡特零件查询（AP-655C） 190-6469: LINES GP-PROPEL

广数供应链运营团队, 16 02月, 2025，浏览： 243 次

Pos.	Part No	Qty	Parts name
1.	5V-6152	[2]	CLAMP
2.	7R-7942	[2]	CLAMP
3.	7R-7951	[1]	PLATE
4.	7R-7952	[1]	COVER
5.	8W-3744I	[1]	HOSE AS
6.	9C-2399I	[1]	HOSE AS
7.	138-4572	[1]	COVER
8.	139-1456I	[1]	HOSE AS
9.	142-6815I	[1]	HOSE AS
10.	148-0342	[2]	CLAMP
11.	154-4887	[1]	PLATE AS
12.	177-1061	[1]	ELBOW AS
	5K-9090	[1]	SEAL-O-RING
	142-0038	[1]	ELBOW
13.	178-8510	[1]	PLATE-WELD
14.	202-9651	[1]	TUBE AS
15.	202-9652	[1]	TUBE AS
16.	204-2662I	[1]	HOSE AS
17.	204-4413I	[1]	HOSE AS
18.	204-4414I	[1]	HOSE AS
19.	204-4415I	[1]	HOSE AS
20.	204-4424I	[1]	HOSE AS
21.	204-4426I	[1]	HOSE AS
22.	204-4454I	[1]	HOSE AS
23.	204-4455I	[1]	HOSE AS
24.	204-4456I	[1]	HOSE AS
25.	204-4457I	[1]	HOSE AS
26.	204-7163	[1]	PLATE AS
27.	204-7199	[1]	PLATE
28.	205-9342	[6]	CLAMP
29.	205-9343	[2]	COVER
30.	206-7013	[8]	FASTENER
31.	207-0603	[4]	PLATE-COVER
32.	207-4499	[3]	PLATE-COVER
33.	216-7167	[8]	CLAMP-HALF
34.	1P-3703	[3]	SEAL-RECTANGULAR
35.	1P-5766	[6]	FLANGE-HALF
36.	1S-0994	[2]	CLIP(LOOP)(LADDER)
37.	206-6415	[6]	CLAMP-HALF
38.	4F-7391	[2]	SEAL-O-RING
39.	5K-9090	[2]	SEAL-O-RING
40.	5P-4115	[1]	WASHER-HARD(7.2X19X2-MM THK)
41.	6V-1889	[3]	CLIP(LOOP)(SLOT)
42.	7X-2535M	[2]	BOLT(M6X1X60-MM)
43.	8C-6877	[20]	BOLT(7/16-14X1.75-IN)
44.	8S-0948	[2]	CLIP(SLOT)
45.	8T-3844M	[1]	BOLT(M6X1X70-MM)
46.	8T-5005M	[6]	BOLT(M10X1.5X70-MM)
47.	8T-5360	[20]	WASHER(12X22.5X2.5-MM THK)
48.	8T-6466M	[8]	BOLT(M10X1.5X60-MM)
49.	8T-6869M	[1]	BOLT(M8X1.25X60-MM)
50.	8T-6870M	[1]	BOLT(M8X1.25X70-MM)
51.	8T-6912M	[1]	BOLT(M8X1.25X50-MM)
52.	8T-6974M	[1]	BOLT(M6X1X80-MM)
53.	204-4309	[1]	PLATE AS
54.	8T-4121	[3]	WASHER-HARD(11X21X2.5-MM THK)
55.	8T-4172M	[3]	BOLT(M10X1.5X80-MM)
	I		REFER TO HYDRAULIC INFORMATION SYSTEM
	M		METRIC PART
