| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 205-8476 | [1] | BRACKET AS | |
| 2. | 205-8477 | [1] | BRACKET | |
| 3. | 205-8480 | [1] | BRACKET AS | |
| 4. | 205-8485 | [1] | COVER AS | |
| 5. | 205-8486 | [1] | COVER AS | |
| 6. | 5P-4116 | [10] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 7. | 8T-4122 | [2] | WASHER-HARD(17X32X3.5-MM THK) | |
| 8. | 8T-4190M | [2] | BOLT(M16X2X25-MM) | |
| 9. | 8T-4200M | [8] | BOLT(M8X1.25X16-MM) | |
| 10. | 8T-4908M | [2] | BOLT(M8X1.25X25-MM) | |
| M | METRIC PART | |||
