卡特零件查询（AP-655C） 192-3779: VENTILATION GP-PAVER
广数供应链运营团队, 16 02月, 2025，浏览：
117 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4W-7627 | [2] | SPACER(11X19X37-MM THK) | |
| 2. | 5P-0600 | [2] | CLAMP-HOSE | |
| 3. | 6W-9789 | [1] | BAR | |
| 4. | 143-3500 | [1] | INLET-BLOWER | |
| 5. | 147-5457 | [1] | PLATE | |
| 6. | 147-6259 | [1] | COVER AS | |
| 7. | 147-6956 | [1] | BLOWER GP-PAVER VENTILATION | |
| | 3B-8601 | [2] | SETSCREW-SOCKET(3/8-16X0.5-IN) | |
| 8. | 147-8904 | [1] | HOUSING AS-BLOWER | |
| 9. | 150-8702 | [1] | GAUGE-DIFFERENTIAL PRESSURE | |
| 10. | 150-8703 | [1] | BRACKET-GAUGE | |
| 11. | 171-1082 | [1] | DUCT AS | |
| 12. | 190-9961Y | [1] | MOTOR & MTG GP-VENTILATION | |
| 13. | 195-4966 | [1] | HOSE | |
| 14. | 198-6172Y | [1] | LINES GP-PAVER VENTILATION | |
| 15. | 205-2426 | [1] | DUCT AS | |
| 16. | 213-9359 | [1] | ANGLE | |
| 17. | 217-5202 | [1] | SCREEN | |
| 18. | 222-9208 | [1] | TUBE | |
| 19. | 222-9210 | [1] | STACK AS | |
| 20. | 5C-7261M | [5] | NUT(M8X1.25-THD) | |
| 21. | 5C-9553M | [5] | BOLT(M6X1X16-MM) | |
| 22. | 5P-4116 | [10] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 23. | 6V-7743M | [5] | LOCKNUT(M6X1-THD) | |
| 24. | 8M-2771 | [1] | CLIP | |
| 25. | 8T-4121 | [12] | WASHER-HARD(11X21X2.5-MM THK) | |
| 26. | 8T-4133M | [2] | NUT(M10X1.5-THD) | |
| 27. | 8T-4137M | [8] | BOLT(M10X1.5X20-MM) | |
| 28. | 7X-7877BE | | STRIP-EDGE | |
| 29. | 8T-4200M | [8] | BOLT(M8X1.25X16-MM) | |
| 30. | 8T-4205 | [26] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 31. | 8T-4224 | [10] | WASHER-HARD(8.8X16X2-MM THK) | |
| 32. | 8T-6869M | [2] | BOLT(M8X1.25X60-MM) | |
| 33. | 8T-7547M | [5] | BOLT(M8X1.25X30-MM) | |
| 34. | 8T-9364 | [16] | BOLT(1/4-20X0.625-IN) | |
| 35. | 144-0195E | | HOSE(4CM) | |
| | B | | USE AS REQUIRED |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
