卡特零件查询（AP-655C） 191-4422: AUGER GP
广数供应链运营团队, 16 02月, 2025，浏览：
249 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8T-5439 | [4] | WASHER-HARD(21.5X45X6-MM THK) | |
| 2. | 3P-9111 | [2] | SPACER(23X41.3X19-MM THK) | |
| 3. | 8T-6868M | [10] | BOLT(M12X1.75X80-MM) | |
| 4. | 191-4421Y | [1] | CONVEYOR GP-AUGER | |
| 5. | 191-4423 | [1] | PLATE | |
| 6. | 192-3371 | [2] | BAR | |
| 7. | 192-4529 | [2] | BAR | |
| 8. | 192-4532 | [2] | PLATE AS | |
| | | | (EACH INCLUDES) |
| | 7T-1099 | [2] | LINK | |
| 9. | 192-4533 | [2] | ANGLE | |
| 10. | 123-0354M | [10] | SCREW-FLAT HEAD(M12X1.75X35-MM) | |
| 11. | 168-7789M | [4] | BOLT(M16X2X55-MM) | |
| 12. | 6V-7688M | [2] | LOCKNUT(M20X2.5-THD) | |
| 13. | 7X-2563M | [6] | BOLT(M20X2.5X60-MM) | |
| 14. | 8T-4123 | [12] | WASHER(3.62X5.75X0.375-MM THK) | |
| 15. | 8T-4131M | [6] | NUT(M20X2.5-THD) | |
| 16. | 8T-4132M | [4] | NUT(M16X2-THD) | |
| 17. | 8T-4187M | [2] | BOLT(M20X2.5X80-MM) | |
| 18. | 8T-4223 | [28] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 19. | 8T-4244M | [10] | NUT(M12X1.75-THD) | |
| 20. | 8T-4648M | [8] | BOLT(M12X1.75X70-MM) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
