| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 142-1322 | [1] | COVER | |
| 2. | 142-1398 | [2] | SCREW-PAN HEAD | |
| 3. | 142-1399 | [2] | SPACER | |
| 4. | 9G-0011 | [1] | SWITCH AS-TOGGLE(MAT DEPTH/JOG) | |
| 3L-8187 | [3] | LOCKWASHER | ||
| 6T-3631 | [2] | NUT-HEX(15/32-32-THD) | ||
| 6T-3632 | [1] | LOCKWASHER | ||
| 6T-3633 | [1] | RING-LOCKING | ||
| 6V-8374 | [3] | SCREW-MACHINE(6-32X0.25-IN) | ||
| 5. | 142-1325 | [1] | SEAL-BUSHING | |
| 6. | 142-1326 | [1] | GASKET | |
| 7. | 142-1400 | [2] | SPACER | |
| 8. | 142-1401 | [2] | SCREW | |
| 9. | 220-1376 | [1] | COVER |
