卡特零件查询（AP-655C） 267-6648: MOTOR & MTG GP-VENTILATION
广数供应链运营团队, 16 02月, 2025，浏览：
946 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 266-9833J | [1] | MOTOR GP-GEAR(PAVER VENTILATION)(PAVER VENTILATION) | |
| 2. | 148-8374 | [1] | ELBOW AS | |
| | 3K-0360 | [1] | SEAL-O-RING | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 6V-8723 | [1] | ELBOW | |
| 3. | 150-3036 | [1] | ELBOW AS | |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 8T-1905 | [1] | ELBOW | |
| 4. | 8T-4121 | [2] | WASHER-HARD(11X21X2.5-MM THK) | |
| 5. | 8T-4133M | [2] | NUT(M10X1.5-THD) | |
| 6. | 8T-4195M | [2] | BOLT(M10X1.5X30-MM) | |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 260-5511J | [1] | KIT-SEAL(PAVER VENTILATION MOTOR) | |
| | | | (INCLUDES RINGS, SEALS, O-RINGS, % LIP SEAL) |
| | J | | (KIT MARKED J SERVICES PART(S) MARKED J) |
| | M | | METRIC PART |
