| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 245-0768 | [1] | BRACKET AS | |
| 6V-9632M | [4] | NUT-WELD(M6X1-THD) | ||
| 2. | 245-1106 | [1] | BRACKET | |
| 3. | 245-1107 | [1] | BRACKET | |
| 4. | 245-1108 | [1] | BRACKET | |
| 5. | 245-1109 | [1] | LATCH AS | |
| 6. | 4M-0061 | [4] | BOLT(5/16-18X0.75-IN) | |
| 7. | 5C-9553M | [2] | BOLT(M6X1X16-MM) | |
| 8. | 8T-4224 | [4] | WASHER-HARD(8.8X16X2-MM THK) | |
| 9. | 8T-4971M | [2] | BOLT(M6X1X30-MM) | |
| 10. | 9X-8256 | [4] | WASHER(6.6X12X2-MM THK) | |
| M | METRIC PART | |||
