卡特零件查询（AP-655D） 475-6227: KIT-AUGER
广数供应链运营团队, 16 02月, 2025，浏览：
875 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 106-9718Y | [2] | BEARING GP-AUGER(END SECTION) | |
| | 382-5519Y | [2] | BEARING GP-AUGER(CENTER) | |
| | 8T-4137M | [4] | BOLT(M10X1.5X20-MM) | |
| | 8T-4176M | [2] | BOLT(M12X1.75X90-MM) | |
| | 8T-5001M | [10] | BOLT(M12X1.75X130-MM) | |
| | 7J-8902 | [4] | BOLT-12 POINT HEAD(5/8-11X1.5-IN) | |
| | 6V-8200M | [8] | BOLT-SOCKET HEAD(M12X1.75X35-MM) | |
| | 167-8109 | [1] | DEFLECTOR | |
| | 136-9390 | [4] | KEY | |
| | 6V-7687M | [12] | LOCKNUT(M12X1.75-THD) | |
| | 103-3591 | [2] | PIPE | |
| | 8L-9811 | [4] | RING-RETAINING | |
| | 419-6688 | [4] | SEGMENT-HALF AUGER(RH) | |
| | 419-6690 | [4] | SEGMENT-HALF AUGER(LH) | |
| | 419-6691 | [2] | SEGMENT-QUARTER AUGER(INNER, LH; OUTER, RH) | |
| | 419-6693 | [2] | SEGMENT-QUARTER AUGER(OUTER, LH; INNER, RH) | |
| | 310-5239 | [2] | SHAFT-AUGER | |
| | 7X-7729 | [4] | WASHER(11X25X3-MM THK) | |
| | 7X-0588 | [4] | WASHER-HARD(17X27X3.5-MM THK) | |
| | 8T-4223 | [22] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
