卡特零件查询（AP-655D） 266-3172: CONVERSION AR-SCREED
广数供应链运营团队, 17 02月, 2025，浏览：
701 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 265-3707 | [1] | CONTROL GP-BURNER(RH) | |
| | 8D-2676 | [1] | SWITCH AS-TOGGLE(SINGLE POLE)(SCREED HEAT,RH) | |
| | 3L-8187 | [2] | LOCKWASHER | |
| | 6T-3631 | [2] | NUT-HEX(15/32-32-THD) | |
| | 6T-3632 | [1] | LOCKWASHER | |
| | 6T-3633 | [1] | RING-LOCKING | |
| | 6V-8374 | [2] | SCREW-MACHINE(6-32X0.25-IN) | |
| 2. | 265-3833 | [1] | CONTROL GP-BURNER(LH) | |
| | 8D-2676 | [1] | SWITCH AS-TOGGLE(SINGLE POLE)(SCREED HEAT,LH) | |
| | 3L-8187 | [2] | LOCKWASHER | |
| | 6T-3631 | [2] | NUT-HEX(15/32-32-THD) | |
| | 6T-3632 | [1] | LOCKWASHER | |
| | 6T-3633 | [1] | RING-LOCKING | |
| | 6V-8374 | [2] | SCREW-MACHINE(6-32X0.25-IN) | |
| 3. | 266-3171Y | [1] | BOX GP-CONTROL(BURNER) | |
| | Y | | SEPARATE ILLUSTRATION |
