| 1. | 1P-6509 | [1] | KNOB | |
| 2. | 3D-9718 | [1] | SWITCH AS-PUSH BUTTON(HORN) | |
| | 6V-8376 | [2] | SCREW-MACHINE(8-32X0.25-IN) | |
| | 6V-8832 | [1] | NUT(5/8-32-THD) | |
| | 9B-7233 | [2] | LOCKWASHER | |
| 3. | 7C-4550 | [1] | SEAL(ROTATING SHAFT) | |
| 4. | 7N-5876 | [1] | LAMP(24-VOLT, 0.2-AMPERE)(MINIATURE) | |
| 5. | 311-5307M | [4] | SCREW-BUTTON HEAD(M6X1X16-MM) | |
| 6. | 347-8607 | [1] | KNOB(PARKING BRAKE)(RED) | |
| 7. | 116-5275 | [1] | SWITCH GP-PUSH BUTTON(OPERATOR)(EMERGENCY STOP) | |
| 8. | 116-5277 | [2] | BLOCK(CONTACT) | |
| 9. | 116-6565 | [1] | BLOCK AS(LIGHT) | |
| | 8L-9801 | [1] | LAMP(12-VOLT) | |
| 10. | 246-8912 | [2] | SWITCH GP-TOGGLE(CONVEYOR CONTROL) | |
| 10A. | 246-8912 | [1] | SWITCH GP-TOGGLE(TOW POINT CONTROL, LH) | |
| 10B. | 246-8912 | [1] | SWITCH GP-TOGGLE(EXTENDER WIDTH, LH) | |
| 10C. | 246-8912 | [1] | SWITCH GP-TOGGLE(AUGER CONTROL) | |
| 10D. | 246-8912 | [1] | SWITCH GP-TOGGLE(TOW POINT CONTROL, RH) | |
| | | | (EACH SWITCH AS INCLUDES) |
| | 3L-8187 | [3] | LOCKWASHER | |
| | 6T-3631 | [2] | NUT-HEX(15/32-32-THD) | |
| | 6T-3632 | [1] | LOCKWASHER | |
| | 6T-3633 | [1] | RING-LOCKING | |
| | 6V-8374 | [3] | SCREW-MACHINE(6-32X0.25-IN) | |
| 11. | 265-9984 | [1] | BRACKET | |
| 13. | 288-6125Y | [1] | BOX GP-SCREED CONTROL(LH) | |
| 14. | 288-6126 | [1] | FILM-IDENTIFICATION(CONTROL PANEL) | |
| 15. | 289-6057 | [1] | PLATE | |
| 16. | 293-0069 | [1] | HARNESS AS-BOX(LH) | |
| | 8D-9537 | [1] | CAP-DUST | |
| | 131-4888 | [1] | GASKET | |
| | 131-4889 | [1] | GASKET | |
| | 8Q-1191 | [1] | CAP-PROTECTION | |
| | 9X-3401 | [26] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 155-2260 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | 155-2270 | [1] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 9G-3695 | [15] | PLUG-SEAL | |
| | 5S-3657 | [1] | RECEPTACLE AS-CONNECTOR(10-PIN) | |
| | 9X-0481 | [1] | RECEPTACLE AS-CONNECTOR(6-PIN) | |
| | 9X-1343 | [1] | RECEPTACLE AS-CONNECTOR(40-PIN) | |
| | 180-9340 | [4] | SOCKET-CONNECTOR(14-GA TO 18-GA) | |
| | 5P-2321 | [28] | TERMINAL-FORK(14-GA TO 16-GA, NO. 6 SCREW) | |
| 17. | 340-1070 | [1] | POTENTIOMETER AS(AUGER CONTROL) | |
| 18. | 191-1035 | [1] | PLUG | |
| 19. | 9X-8256 | [4] | WASHER(6.6X12X2-MM THK) | |
| 20. | 322-5692 | [1] | LAMP GP-INDICATOR | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 9X-3401 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 5P-5677D | | WIRE(18-GA, BLACK)(0.4-M) | |
| | 270-5061 | [1] | LAMP-INDICATOR(GREEN) | |
| 21. | 096-6166 | [4] | WASHER-HARD(4.5X9X1-MM THK) | |
| 22. | 155-4098M | [8] | SCREW-BUTTON HEAD(M3X0.5X1-MM) | |
| 23. | 162-2165M | [4] | BOLT-SOCKET HEAD(M4X0.7X16-MM) | |
| 24. | 7K-1181 | [3] | STRAP-CABLE | |
| | D | | ORDER BY THE METER |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
