卡特零件查询（AP-655D） 353-9489: FRAME GP-SCREED
广数供应链运营团队, 17 02月, 2025，浏览：
545 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 353-9490 | [1] | FRAME AS(RH) | |
| 2. | 353-9512 | [2] | SUPPORT AS | |
| 3. | 360-5646 | [2] | COVER | |
| 4. | 361-3891 | [4] | SUPPORT AS | |
| 5. | 361-5157 | [2] | COVER | |
| 6. | 342-9914M | [12] | BOLT-FLANGE HEAD(M10X1.5X25-MM) | |
| 7. | 7X-0515 | [10] | WASHER-HARD(17X35X5-MM THK) | |
| 8. | 7X-2552M | [8] | BOLT(M16X2X30-MM) | |
| 9. | 8T-4139M | [4] | BOLT(M12X1.75X30-MM) | |
| 10. | 8T-4140M | [2] | BOLT(M16X2X60-MM) | |
| 11. | 8T-4223 | [4] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 12. | 8T-7338M | [14] | BOLT(M16X2X45-MM) | |
| 13. | 371-0016 | [1] | FRAME AS(LH) | |
| 14. | 198-4780 | [10] | WASHER-HARD(17.5X32X8-MM THK) | |
| 15. | 228-4798 | [4] | FILM-IDENTIFICATION(GROUND) | |
| 16. | 229-5048 | [2] | FILM-WARNING(SHOCK HAZARD, READ OMM) | |
| 17. | 323-4689 | [2] | FILM-WARNING(SHOCK, ELECTROCUTION HAZARD) | |
| | M | | METRIC PART |
