卡特零件查询（AP-655D） 259-7137: PLANETARY GP-FINAL DRIVE
广数供应链运营团队, 17 02月, 2025，浏览：
360 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 272-0235 | [1] | HUB | |
| 2. | 7T-2459 | [1] | SEAL GP-DUO-CONE | |
| 3. | 207-2818 | [3] | PIN | |
| 4. | 151-7491 | [2] | RING-RETAINING | |
| 5. | 207-2819 | [9] | WASHER-ANTIROTATION(42.5X64X1.5-MM THK) | |
| 6. | 151-7496 | [3] | GEAR-PLANETARY | |
| 7. | 151-7513 | [225] | NEEDLE | |
| 8. | 151-7507 | [3] | PIN-GEAR | |
| 9. | 151-7510 | [150] | NEEDLE | |
| 10. | 151-7515 | [3] | PIN | |
| 11. | 151-7508 | [3] | GEAR-PLANETARY | |
| 12. | 273-3142 | [3] | RING | |
| 13. | 151-7500 | [3] | WASHER-GEAR | |
| 14. | 191-2295 | [3] | GEAR-PLANETARY | |
| 15. | 136-8638 | [1] | RING-RETAINING | |
| 16. | 151-7502 | [3] | WASHER-ANTIROTATION | |
| 17. | 151-7505 | [3] | RING-RETAINING | |
| 18. | 151-7497 | [3] | WASHER-ANTIROTATION | |
| 19. | 151-7504 | [3] | PIN-GEAR | |
| 20. | 151-7506 | [54] | NEEDLE | |
| 21. | 151-7501 | [2] | DISC | |
| 22. | 9X-6422 | [1] | RING-RETAINING | |
| 23. | 191-4441 | [1] | KIT-SHIM(COVER PAD) | |
| | | | (INCLUDES SHIMS) |
| 24. | 191-2287 | [1] | PAD | |
| 25. | 191-0065 | [1] | GEAR-INPUT SUN | |
| 26. | 272-0233 | [1] | COVER-OUTPUT | |
| 27. | 136-8647 | [2] | PLUG | |
| 28. | 241-6180 | [2] | WASHER(10X14X1-MM THK) | |
| 29. | 191-2294 | [1] | CARRIER-PLANETARY | |
| 30. | 136-8641 | [1] | SEAL-O-RING | |
| 31. | 151-7484 | [1] | GEAR-SUN | |
| 32. | 095-9805M | [15] | BOLT-SOCKET HEAD(M14X2X40-MM) | |
| 33. | 272-0234 | [1] | GEAR-INPUT RING | |
| 34. | 5P-2545 | [1] | SEAL-O-RING | |
| 35. | 151-7509 | [1] | CARRIER-PLANETARY | |
| 36. | 095-0707M | [6] | BOLT(M16X2X120-MM) | |
| 37. | 272-0232 | [1] | SHAFT | |
| 38. | 151-7488 | [1] | CARRIER-PLANETARY | |
| 39. | 151-7481 | [1] | GEAR-OUTPUT | |
| 40. | 151-7490 | [6] | BUSHING | |
| 41. | 151-3084 | [2] | CONE | |
| 42. | 251-9614 | [1] | KIT-SHIM(PARKING BRAKE) | |
| | | | (INCLUDES SHIMS) |
| 43. | 207-2814 | [1] | SEAL-O-RING | |
| 44. | 177-0014 | [1] | DISC-RETAINING | |
| 45. | 136-8068 | [6] | DISC-MIDDLE | |
| 46. | 177-0013 | [1] | PISTON-BRAKE | |
| 47. | 191-2281 | [1] | WASHER-RETAINING | |
| 48. | 2Y-8422M | [1] | SCREW(M6X16-MM) | |
| 49. | 095-7952 | [1] | RING | |
| 50. | 207-2817 | [16] | SPRING | |
| 51. | 136-8064 | [5] | DISC-FRICTION | |
| 52. | 207-2813 | [1] | SEAL-O-RING | |
| 53. | 151-7517 | [2] | SEAL-O-RING | |
| 54. | 191-2288 | [1] | PLUG-ORIFICE | |
| 55. | 207-2816 | [1] | RING-BACKUP | |
| 56. | 207-2815 | [1] | RING-BACKUP | |
| 57. | 151-3085 | [2] | CUP | |
| 58. | 387-4396 | [1] | COUPLING-GEAR | |
| 59. | 387-4399 | [1] | DISC-RETAINING | |
| | M | | METRIC PART |
