久保田零件查询T12602 ROPS HOOD(BONNET) AND CHASSISEPC Kubota online
广数供应链运营团队, 17 02月, 2025，浏览：
282 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
9999999999
|
[1] |
FRAME ROPS LH
|
0.0000(lbs); 0.000
|
| 020. |
9999999999
|
[1] |
FRAME ROPS RH
|
0.0000(lbs); 0.000
|
| 030. |
3815034730
|
[2] |
BRACKET CHAIN
|
5.3680(lbs); 2.440
|
| 040. |
3243034740
|
[8] |
BOLT
|
0.6600(lbs); 0.300
|
| 050. |
9999999999
|
[2] |
BRACKET JOINT
|
0.0000(lbs); 0.000
|
| 060. |
0117351428
|
[4] |
BOLT
|
0.1078(lbs); 0.049
|
| 070. |
0451250140
|
[4] |
WASHER SPRING
|
0.0154(lbs); 0.007
|
| 080. |
9999999999
|
[1] |
FRAME ROPS UPPER
|
0.0000(lbs); 0.000
|
| 090. |
0451250140
|
[8] |
WASHER SPRING
|
0.0154(lbs); 0.007
|
| 100. |
3508018550
|
[1] |
ASSY BELT SEAT
|
1.6500(lbs); 0.750
|
| 110. |
3508018480
|
[2] |
BRACKET SEAT BELT
|
0.2200(lbs); 0.100
|
| 120. |
0177451025
|
[1] |
BOLT FLANGE
|
0.0440(lbs); 0.020
|
| 130. |
0177451030
|
[1] |
BOLT FLANGE
|
0.0572(lbs); 0.026
|
| 140. |
0211650100
|
[2] |
NUT
|
0.0088(lbs); 0.004
|
