卡特零件查询（AP500F） 447-9806: MOTOR & MTG GP-PROPEL
广数供应链运营团队, 17 02月, 2025，浏览：
811 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 499-7348Y | [2] | MOTOR GP-PISTON | |
| 2. | 148-8315 | [2] | CONNECTOR AS | |
| | | | (EACH INCLUDES) |
| | 2M-9780 | [1] | SEAL-O-RING | |
| | 6V-8642 | [1] | CONNECTOR | |
| | 7J-9108 | [1] | SEAL-O-RING | |
| 3. | 148-8336 | [2] | CONNECTOR AS | |
| | | | (EACH INCLUDES) |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 6V-8636 | [1] | CONNECTOR | |
| 4. | 192-5168 | [2] | SEAL-O-RING | |
| 5. | 8T-4123 | [4] | WASHER(22X35X3.5-MM THK) | |
| 6. | 8T-6430M | [4] | BOLT(M20X2.5X50-MM) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
