| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 540-1705M | [2] | SETSCREW(M5X0.8X10-MM) | |
| 2. | 6L-7138 | [4] | SCREW(8-32X0.31-IN) | |
| 3. | 378-5551 | [1] | RECEPTACLE AS | |
| 4. | 565-3048 | [1] | SENSOR GP-POSITION(LINEAR) | |
| 118-8586 | [1] | SEAL-O-RING | ||
| 420-5767 | [1] | RING-BACKUP | ||
| 5. | 493-4194 | [2] | PLUG-PORT | |
| AVAILABLE REPAIR KIT(S): | ||||
| 450-4472 | [1] | KIT-SEAL | ||
| (INCLUDES WIPER SEAL, U-CUP SEAL, O-RING SEAL, BACK-UP RING, PISTON SEAL, O-RING SEALS, RING WEARS) | ||||
| M | METRIC PART | |||
