卡特零件查询（AP500F） 438-1848: EXTENSION GP-SCREED
广数供应链运营团队, 17 02月, 2025，浏览：
535 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 438-1652Y | [1] | CYL & MTG GP-SCREED EXTENSION | |
| 2. | 441-9880Y | [1] | WIRING GP-SENSOR | |
| 3. | 450-0989 | [2] | SENSOR GP-POSITION(SCREED EXTENSION, RH, LH) | |
| 3A. | 450-0989 | [1] | SENSOR GP-POSITION(CROWN) | |
| 4. | 450-0990 | [2] | SENSOR GP-POSITION(ANGLE OF ATTACK, RH, LH) | |
| 5. | 477-3224C | [1] | PLATE AS | |
| 6. | 477-3225C | [1] | PLATE AS | |
| 7. | 451-9230 | [2] | PLATE AS | |
| | | | (EACH PLATE AS INCLUDES) |
| | 8T-3490M | [1] | NUT-WELD(M10X1.5-THD) | |
| 8. | 7X-7729 | [4] | WASHER(11X25X3-MM THK) | |
| 9. | 8T-4121 | [4] | WASHER-HARD(11X21X2.5-MM THK) | |
| 10. | 8T-4136M | [4] | BOLT(M10X1.5X25-MM) | |
| 11. | 8T-4138M | [4] | BOLT(M6X1X20-MM) | |
| 12. | 9X-8256 | [4] | WASHER(6.6X12X2-MM THK) | |
| 13. | 9X-2038 | [1] | WASHER(7X19X2-MM THK) | |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
