| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 225-7944 | [1] | GASKET | |
| 2. | 232-3751 | [1] | PLATE | |
| 3. | 6I-0572M | [4] | BOLT(M8X1.25X20-MM) | |
| 4. | 6I-0645M | [5] | BOLT(M8X1.25X25-MM) | |
| 5. | 330-9847 | [1] | GASKET | |
| 6. | 484-5165 | [1] | ADAPTER | |
| 7. | 361-1225Y | [1] | COOLER GP-ENGINE OIL | |
| M | METRIC PART | |||
| Y | SEPARATE ILLUSTRATION | |||
