卡特零件查询（AP555F） 447-9810: MOTOR & MTG GP-CONVEYOR

广数供应链运营团队, 17 02月, 2025，浏览： 455 次

Pos.	Part No	Qty	Parts name
1.	161-9916	[2]	ADAPTER AS
			(EACH INCLUDES)
	2M-9780	[1]	SEAL-O-RING
	6V-7420	[1]	ADAPTER
2.	196-2036	[2]	TEE AS
			(EACH INCLUDES)
	3K-0360	[1]	SEAL-O-RING
	6V-8398	[1]	SEAL-O-RING
	9X-2492	[1]	TEE-O-RING
3.	205-0598	[2]	ELBOW AS
			(EACH INCLUDES)
	3K-0360	[1]	SEAL-O-RING
	6V-8397	[1]	SEAL-O-RING
	118-9080	[1]	ELBOW
4.	241-6215	[2]	ELBOW AS
			(EACH INCLUDES)
	3J-1907	[1]	SEAL-O-RING
	6V-8076	[1]	ELBOW
5.	392-5513Y	[2]	MOTOR GP-PISTON(AUGER)
6.	107-3120	[2]	SEAL-O-RING
7.	148-8309	[2]	ADAPTER AS
			(EACH INCLUDES)
	2P-8421	[1]	ADAPTER-O-RING
	3D-2824	[1]	SEAL-O-RING
8.	148-8327	[4]	CONNECTOR AS
			(EACH INCLUDES)
	3D-2824	[1]	SEAL-O-RING
	6V-8637	[1]	CONNECTOR
	6V-9746	[1]	SEAL-O-RING
9.	148-8372	[2]	ELBOW AS
			(EACH INCLUDES)
	2M-9780	[1]	SEAL-O-RING
	6V-8398	[1]	SEAL-O-RING
	6V-8721	[1]	ELBOW
10.	155-7321	[2]	ADAPTER AS
			(EACH INCLUDES)
	3D-2824	[1]	SEAL-O-RING
	6V-1722	[1]	ADAPTER
11.	164-5567	[4]	COUPLER AS-QUICK DISCONNECT(MALE)
			(EACH INCLUDES)
	6V-3965	[1]	FITTING(QUICK DISCONNECT)
	214-7568	[1]	SEAL-O-RING
12.	164-5619	[2]	PLUG AS
			(EACH INCLUDES)
	2M-9780	[1]	SEAL-O-RING
	9S-8006	[1]	PLUG(7/8-14-THD)
13.	194-2903	[2]	ELBOW AS
			(EACH INCLUDES)
	3K-0360	[1]	SEAL-O-RING
	8T-0119	[1]	ELBOW
14.	5P-1076	[4]	WASHER-HARD(13.5X30X4-MM THK)
15.	6V-0852	[4]	CAP-DUST
16.	8T-4956M	[4]	BOLT(M12X1.75X35-MM)
	M		METRIC PART
	Y		SEPARATE ILLUSTRATION
