Pos.	Part No	Qty	Parts name
1.	5R-5718	[1]	PLUG-DUST
2.	5R-5719	[1]	CAP-DUST
3.	5R-6305	[1]	COUPLER AS-QUICK DISCONNECT(MALE)
4.	7R-7951	[1]	PLATE
5.	142-8949	[1]	FITTING AS(QUICK DISCONNECT, FEMALE)
6.	165-5695	[1]	CAP-DUST
7.	173-7638	[1]	FITTING AS
	191-6944	[1]	KIT-SEAL
			(INCLUDES O-RING & SEALS)
8.	187-5302	[1]	CAP-DUST
9.	302-1413	[1]	ADAPTER AS
	2M-9780	[1]	SEAL-O-RING
	7X-3165	[1]	ADAPTER
10.	338-9567I	[1]	HOSE AS
11.	364-4570	[1]	STRAP
12.	423-4902	[1]	BRACKET AS
13.	432-6206	[1]	PLATE AS
14.	432-6209	[1]	PLATE AS
15.	432-6210	[1]	PLATE AS
16.	445-5241I	[1]	HOSE AS
17.	445-5242I	[1]	HOSE AS
18.	445-5243I	[1]	HOSE AS
19.	445-5244I	[1]	HOSE AS
20.	148-8352	[1]	ELBOW AS
	5K-9090	[1]	SEAL-O-RING
	6V-9854	[1]	ELBOW(SWIVEL)
21.	148-8392	[1]	ELBOW AS
	6V-9746	[1]	SEAL-O-RING
	6V-9853	[1]	ELBOW
22.	155-6344	[1]	ELBOW AS
	5K-9090	[2]	SEAL-O-RING
	6V-8991	[1]	ELBOW
23.	164-5548	[1]	COUPLING AS
	4I-6141	[1]	ADAPTER
	7M-8485	[1]	SEAL-O-RING
24.	165-4933	[2]	ELBOW AS
			(EACH INCLUDES)
	6V-8990	[1]	ELBOW
	6V-9746	[2]	SEAL-O-RING
25.	177-2215	[1]	STRAP-DUAL CLAMP
26.	190-9821	[1]	ELBOW AS
	6V-8989	[1]	ELBOW
	7J-9108	[2]	SEAL-O-RING
27.	2P-1293	[2]	LOCKNUT(1-3/16-12-THD)
28.	330-9753	[1]	ADAPTER AS
	3D-2824	[1]	SEAL-O-RING
	5P-2211	[1]	ADAPTER(1-1/16-12-THD)
29.	3D-2824	[2]	SEAL-O-RING
30.	5R-6304	[1]	COUPLER AS-QUICK DISCONNECT(FEMALE)
31.	6V-9170	[1]	NUT-BULKHEAD(1-14-THD)
32.	6V-9172	[1]	NUT(1-7/16-12-THD)
33.	7R-0042	[2]	ADAPTER
34.	7R-7941	[2]	CLAMP
35.	7X-2535M	[2]	BOLT(M6X1X60-MM)
36.	7X-7729	[6]	WASHER(11X25X3-MM THK)
37.	8T-4121	[2]	WASHER-HARD(11X21X2.5-MM THK)
38.	8T-4136M	[6]	BOLT(M10X1.5X25-MM)
39.	8T-4137M	[2]	BOLT(M10X1.5X20-MM)
	I		REFER TO HYDRAULIC INFORMATION SYSTEM
	M		METRIC PART
