| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 476-8641 | [4] | CLAMP | |
| 2. | 393-0666 | [1] | BAR-TAMPER | |
| 3. | 393-0667 | [1] | PLATE-WEAR | |
| 4. | 8T-4121 | [4] | WASHER-HARD(11X21X2.5-MM THK) | |
| 5. | 8T-4137M | [4] | BOLT(M10X1.5X20-MM) | |
| 6. | 8T-4189M | [5] | BOLT(M8X1.25X20-MM) | |
| 7. | 8T-5089 | [4] | PIN-SPRING | |
| M | METRIC PART | |||
