卡特零件查询（AP600F） 428-7047: TURBOCHARGER GP
广数供应链运营团队, 17 02月, 2025，浏览：
982 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 6I-4045M | [4] | BOLT(M10X1.5X75-MM) | |
| 2. | 100-4454 | [4] | NUT | |
| 3. | 114-2583M | [4] | STUD(M8X25-MM) | |
| 4. | 124-3815M | [1] | BOLT(M8X1.25X16-MM) | |
| 5. | 317-9229 | [2] | CLAMP-HOSE | |
| 6. | 342-6435 | [1] | PIPE-EXHAUST | |
| 7. | 343-5908 | [1] | CLAMP-V BAND | |
| 8. | 343-5910 | [2] | CLAMP-V BAND | |
| 9. | 348-4636 | [4] | STUD | |
| 10. | 348-7736 | [1] | GASKET | |
| 11. | 356-5345 | [1] | HOSE | |
| 12. | 358-8888 | [1] | BRACKET | |
| 13. | 358-9191 | [1] | ELBOW | |
| 14. | 360-1584Y | [1] | LINES GP-TURBOCHARGER AIR(ACTUATOR) | |
| 15. | 421-3007 | [1] | TURBOCHARGER | |
| 16. | 443-0315 | [1] | TURBOCHARGER AS | |
| 17. | 6I-0563M | [4] | NUT(M10X1.5-THD) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
