卡特零件查询（AP600F） 424-9124: WIRING GP-GENERATOR
广数供应链运营团队, 17 02月, 2025，浏览：
763 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 1S-2342 | [2] | STRAP AS-GROUND | |
| 2. | 5P-7958 | [2] | SLEEVE-CABLE SPLICE | |
| 3. | 7K-1181 | [1] | STRAP-CABLE | |
| 4. | 9D-7924 | [6] | MOUNTING AS | |
| 5. | 170-9328C | [2] | STRAP AS-GROUND | |
| 6. | 143-9644 | [1] | PLATE-RETAINER | |
| 7. | 207-4499 | [3] | PLATE-COVER | |
| 8. | 431-4112 | [4] | PLATE | |
| 9. | 431-9627 | [1] | BRACKET AS | |
| | 154-4887 | [1] | PLATE AS | |
| 10. | 434-1847 | [6] | CLAMP-HALF | |
| 11. | 440-8293 | [1] | BRACKET AS | |
| | 8T-3612M | [2] | NUT-WELD(M8X1.25-THD) | |
| | 154-4887 | [1] | PLATE AS | |
| | 178-8508 | [1] | PLATE AS | |
| 12. | 442-9875 | [1] | BRACKET | |
| 13. | 443-0756 | [4] | CLAMP | |
| 14. | 443-0779 | [1] | BRACKET | |
| 15. | 443-1294 | [1] | CABLE AS-BRAIDED(PHASE A) | |
| 16. | 443-1295 | [1] | CABLE AS-BRAIDED(PHASE B) | |
| 17. | 443-1296 | [1] | CABLE AS-BRAIDED(PHASE C) | |
| | | | (EACH CABLE AS INCLUDES) |
| | 363-8992 | [4] | GROMMET AS | |
| | | | (EACH INCLUDES) |
| | 542-8665 | [1] | SEAL-RING | |
| | 1P-0810B | | TAPE-ELECTRICAL | |
| | 2L-8067 | [2] | TERMINAL-RING(10-GA TO 12-GA, 1/4-IN SCREW) | |
| | 9G-4343 | [4] | TERMINAL-RING(4-GA, 1/4-IN SCREW) | |
| | 6V-9023E | | TUBE-HEAT SHRINK(12.7-MM DIA)(10-CM) | |
| 18. | 443-1299 | [1] | HARNESS AS-SCREED | |
| | 1P-0810B | [1] | TAPE-ELECTRICAL | |
| 19. | 566-9528C | [1] | INVERTER GP-POWER(GENERATOR) | |
| | 416-0110 | [1] | FAN AS(9-BLADE) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | 177-9645 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (EACH RECEPTACLE KIT INCLUDES RECEPTACLE AS & WEDGE) |
| | 454-0103 | [1] | GUARD | |
| | 454-0104 | [1] | PLATE | |
| 20. | 449-6291 | [1] | BRACKET AS | |
| | 8T-3490M | [4] | NUT-WELD(M10X1.5-THD) | |
| | 8T-3612M | [3] | NUT-WELD(M8X1.25-THD) | |
| 21. | 450-1091 | [1] | RECEPTACLE AS | |
| 22. | 458-6688 | [1] | BRACKET AS | |
| | 8T-3612M | [3] | NUT-WELD(M8X1.25-THD) | |
| 23. | 463-6652 | [1] | STRAP AS-GROUND | |
| 24. | 470-6563 | [3] | WIRE AS | |
| 25. | 099-3649M | [6] | BOLT(M8X1.25X40-MM) | |
| 26. | 124-7346 | [3] | LOCKWASHER | |
| 27. | 177-2215 | [3] | STRAP-DUAL CLAMP | |
| 28. | 1A-8912 | [6] | WASHER(6.7X12.7X1.6-MM THK) | |
| 29. | 1H-3338 | [4] | LOCKWASHER | |
| 30. | 1V-7368 | [8] | SPACER(0.364X0.54X1.06-IN THK) | |
| 31. | 208-0075 | [2] | CLAMP-HALF | |
| 32. | 214-0910 | [3] | LOCKWASHER | |
| 33. | 238-0251M | [4] | SCREW-BUTTON HEAD(M10X1.5X25-MM) | |
| 34. | 7X-2619M | [6] | BOLT(M6X1X10-MM) | |
| 35. | 384-1628 | [6] | WASHER-HARD(8.8X35X4-MM THK) | |
| 36. | 4B-4274 | [3] | WASHER(5.5X13X1.2-MM THK) | |
| 37. | 4B-4280 | [3] | WASHER(13.5X27X2.5-MM THK) | |
| 38. | 5C-9553M | [3] | BOLT(M6X1X16-MM) | |
| 39. | 5P-0537 | [12] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 40. | 5P-4116 | [11] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 41. | 6I-4374M | [3] | BOLT(M8X1.25X60-MM) | |
| 42. | 6V-8837M | [6] | BOLT(M6X1X16-MM) | |
| 43. | 7I-2272M | [3] | BOLT(M5X0.8X12-MM) | |
| 44. | 7P-1695 | [7] | WASHER(10.5X19X3-MM THK) | |
| 45. | 8T-4121 | [2] | WASHER-HARD(11X21X2.5-MM THK) | |
| 46. | 8T-4133M | [5] | NUT(M10X1.5-THD) | |
| 47. | 8T-4136M | [2] | BOLT(M10X1.5X25-MM) | |
| 48. | 8T-4137M | [2] | BOLT(M10X1.5X20-MM) | |
| 49. | 8T-4200M | [5] | BOLT(M8X1.25X16-MM) | |
| 50. | 8T-4224 | [9] | WASHER-HARD(8.8X16X2-MM THK) | |
| 51. | 8T-4244M | [3] | NUT(M12X1.75-THD) | |
| 52. | 8T-4908M | [4] | BOLT(M8X1.25X25-MM) | |
| 53. | 8T-6869M | [3] | BOLT(M8X1.25X60-MM) | |
| 54. | 8T-6912M | [2] | BOLT(M8X1.25X50-MM) | |
| 55. | 8T-7329M | [3] | BOLT(M8X1.25X55-MM) | |
| 56. | 9X-2480M | [2] | BOLT(M6X1X45-MM) | |
| 57. | 5P-7957 | [1] | LANYARD | |
| 58. | 5P-6025D | | LOCKWIRE(0.2-M EACH) | |
| 59. | 8T-4138M | [1] | BOLT(M6X1X20-MM) | |
| | B | | USE AS REQUIRED |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | D | | ORDER BY THE METER |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
