卡特零件查询（AP600F） 424-9122: SENSOR GP-NITROGEN OXIDE
广数供应链运营团队, 17 02月, 2025，浏览：
207 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3S-2093 | [18] | STRAP-CABLE | |
| 2. | 7K-1181 | [4] | STRAP-CABLE | |
| 3. | 441-5127 | [1] | SENSOR AS-NITROGEN OXIDE(ENGINE OUTPUT) | |
| 4. | 441-5128 | [1] | SENSOR AS-NITROGEN OXIDE(EXHAUST PIPE OUT) | |
| 5. | 421-7786 | [1] | SENSOR AS-AMMONIA(EXHAUST GAS)(DIESEL EXHAUST FLUID) | |
| 6. | 421-7787 | [1] | CONTROLLER AS | |
| 7. | 467-0334 | [1] | PLATE | |
| 8. | 177-2215 | [2] | STRAP-DUAL CLAMP | |
| 9. | 327-0325 | [2] | STRAP-CABLE | |
| 10. | 344-5674M | [2] | NUT(M8X1.25-THD) | |
| 11. | 345-3753 | [2] | MOUNTING-CABLE TIE | |
| 12. | 5C-2890M | [6] | NUT(M6X1-THD) | |
| 13. | 5P-4116 | [4] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 14. | 6V-8490M | [2] | BOLT(M6X1X25-MM) | |
| 15. | 7Y-9099M | [2] | SCREW-TRUSS HEAD(M8X1.25X25-MM) | |
| 17. | 8T-4200M | [2] | BOLT(M8X1.25X16-MM) | |
| 18. | 9X-2044M | [2] | SCREW-TRUSS HEAD(M6X1X16-MM) | |
| 19. | 9X-2045M | [2] | SCREW-TRUSS HEAD(M6X1X20-MM) | |
| 20. | 9X-8256 | [8] | WASHER(6.6X12X2-MM THK) | |
| | M | | METRIC PART |
