卡特零件查询（AP600F） 533-4152: SENSOR GP-SONIC
广数供应链运营团队, 17 02月, 2025，浏览：
583 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 107-4749 | [2] | PLATE | |
| 2. | 146-9410 | [1] | COLLAR | |
| 3. | 187-2082 | [2] | LEVER-CONTROL | |
| 4. | 330-5646 | [4] | MOUNT | |
| 5. | 330-8554 | [1] | CABLE AS | |
| 5A. | 111-1308 | [2] | BUSHING | |
| | 494-3877 | [1] | PLUG AS | |
| | 496-3051 | [1] | PLUG AS | |
| 6. | 331-1991 | [1] | MOUNT AS-SENSOR | |
| 7. | 332-1018 | [2] | PLATE-TAPPED | |
| 8. | 351-4852 | [1] | LEVER-CONTROL | |
| 9. | 372-0971 | [1] | SENSOR AS-SONIC | |
| 10. | 450-9467 | [1] | HANDLE | |
| 11. | 459-6768 | [1] | TUBE AS | |
| 12. | 459-6769 | [1] | MOUNT AS | |
| 13. | 477-0307 | [1] | CLAMP | |
| 14. | 477-0471 | [1] | CLAMP AS | |
| 15. | 477-9126 | [1] | GUIDE | |
| | | | -OR- |
| | 485-4367 | [1] | GUIDE | |
| 16. | 9X-2480M | [4] | BOLT(M6X1X45-MM) | |
| 17. | 495-5599 | [4] | HANDLE | |
| 18. | 509-3627 | [1] | TUBE | |
| 19. | 533-4153 | [1] | MOUNT AS | |
| 20. | 533-4154 | [1] | MOUNT AS | |
| 21. | 533-4155 | [1] | TUBE AS | |
| 22. | 533-4156 | [1] | GUIDE | |
| 23. | 533-4157 | [1] | GUIDE | |
| 24. | 1G-8781 | [4] | CLAMP(HALF) | |
| 25. | 344-5675M | [8] | NUT(M10X1.5-THD) | |
| 26. | 3T-0852M | [2] | LOCKNUT(M8X1.25-THD) | |
| 27. | 5P-4116 | [2] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 28. | 7X-2542M | [1] | BOLT(M8X1.25X150-MM) | |
| 29. | 8T-4121 | [11] | WASHER-HARD(11X21X2.5-MM THK) | |
| 30. | 8T-4136M | [2] | BOLT(M10X1.5X25-MM) | |
| 31. | 8T-4177M | [1] | BOLT(M8X1.25X90-MM) | |
| 32. | 8T-4223 | [4] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 33. | 8T-4224 | [4] | WASHER-HARD(8.8X16X2-MM THK) | |
| 34. | 8T-4956M | [4] | BOLT(M12X1.75X35-MM) | |
| 35. | 8T-7547M | [2] | BOLT(M8X1.25X30-MM) | |
| | M | | METRIC PART |
