| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 8T-4184M | [20] | BOLT(M12X1.75X45-MM) | ||
| 415-4096 | [1] | GUARD AS(LH) | ||
| 415-4097 | [1] | GUARD AS(RH) | ||
| 415-4098 | [2] | GUARD AS(REAR) | ||
| (EACH GUARD AS INCLUDES) | ||||
| 5M-7937 | [2] | DOWEL | ||
| 8T-3597M | [2] | NUT-WELD(M12X1.75-THD) | ||
| 566-7836 | [1] | GUARD AS | ||
| 566-7838 | [1] | GUARD AS | ||
| 8T-4223 | [20] | WASHER-HARD(13.5X25.5X3-MM THK) | ||
| M | METRIC PART | |||
