| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 6I-0572M | [1] | BOLT(M8X1.25X20-MM) | |
| 2. | 156-6964M | [1] | BOLT(M8X1.25X30-MM) | |
| 3. | 347-9981 | [1] | PIPE-BREATHER(INLET) | |
| 4. | 356-8338 | [1] | VALVE AS(DRAIN) | |
| 3E-6749 | [1] | SEAL-O-RING | ||
| 5. | 448-5787 | [1] | PIPE | |
| M | METRIC PART | |||
广数供应链运营团队, 17 02月, 2025，浏览： 147 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 6I-0572M | [1] | BOLT(M8X1.25X20-MM) | |
| 2. | 156-6964M | [1] | BOLT(M8X1.25X30-MM) | |
| 3. | 347-9981 | [1] | PIPE-BREATHER(INLET) | |
| 4. | 356-8338 | [1] | VALVE AS(DRAIN) | |
| 3E-6749 | [1] | SEAL-O-RING | ||
| 5. | 448-5787 | [1] | PIPE | |
| M | METRIC PART | |||
