卡特零件查询（AP655F） 436-1383: LINES GP-FUEL
广数供应链运营团队, 17 02月, 2025，浏览：
518 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 6I-0631M | [2] | BOLT(M6X1X12-MM) | |
| 2. | 6I-0846M | [1] | BOLT(M6X1X14-MM) | |
| 3. | 124-3815M | [3] | BOLT(M8X1.25X16-MM) | |
| 4. | 347-3429 | [1] | CLIP-PIPE | |
| 5. | 360-4751 | [2] | CLIP-HARNESS | |
| 6. | 368-8520 | [1] | SUPPORT GP-LINES | |
| | 342-3782 | [1] | CLIP-PIPE | |
| | 347-3429 | [3] | CLIP-PIPE | |
| | 357-9545 | [3] | CLIP-PIPE | |
| 7. | 369-6219 | [1] | BRACKET | |
| 8. | 370-3979 | [1] | LINE AS-FUEL | |
| | 246-4361 | [2] | WASHER(10.5X14X1.5-MM THK) | |
| | 341-3566 | [1] | BOLT | |
| 9. | 372-2838 | [1] | BRACKET GP-SUPPORT(FUEL) | |
| | 347-3429 | [1] | CLIP-PIPE | |
| 10. | 390-5230 | [1] | LINE AS-FUEL | |
| | 355-0632 | [1] | CONNECTOR-SPECIAL | |
| | 381-0011 | [1] | CONNECTOR-FUEL | |
| 11. | 6I-0217M | [5] | BOLT(M8X1.25X20-MM) | |
| 12. | 422-5408 | [1] | SUPPORT GP-LINES | |
| | 357-9545 | [1] | CLIP-PIPE | |
| 13. | 453-9655 | [1] | LINES GP-FUEL | |
| | 228-7089 | [1] | SEAL-O-RING | |
| | 277-4993 | [1] | SEAL-O-RING | |
| 14. | 100-4458M | [1] | BOLT(M8X1.25X14-MM) | |
| | M | | METRIC PART |
