| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 005-8639 | [1] | BEARING-ALIGNING | |
| 2. | 6L-7138 | [4] | SCREW(8-32X0.31-IN) | |
| 3. | 7R-8443 | [2] | PLUG-NYLON | |
| 4. | 4B-9808 | [2] | SETSCREW(1/4-20X0.5-IN) | |
| 5. | 217-3311 | [1] | MAGNET(RING) | |
| 6. | 504-5046 | [1] | SENSOR GP-POSITION(LINEAR) | |
| 118-8586 | [1] | SEAL-O-RING | ||
| 420-5767 | [1] | RING-BACKUP | ||
| 7. | 378-5551 | [1] | RECEPTACLE AS | |
| AVAILABLE REPAIR KIT(S): | ||||
| 443-3186 | [1] | KIT-SEAL | ||
| (INCLUDES PARTS MARKED "K" IN THE GRAPHIC) | ||||
