卡特零件查询（AP655F） 417-2664: PLANETARY GP-AUGER
广数供应链运营团队, 17 02月, 2025，浏览：
805 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8T-0342M | [10] | BOLT-SOCKET HEAD(M10X1.5X80-MM) | |
| 2. | 146-4263 | [2] | SEAL-O-RING | |
| 3. | 8U-2382H | [1] | RING-RETAINING(1-MM THK) | |
| 4. | 514-5255 | [1] | GEAR-SUN | |
| 5. | 144-9773J | [4] | WASHER | |
| 6. | 371-2175J | [1] | BREATHER(AUGER CONVEYOR) | |
| 7. | 371-2032J | [1] | SPACER(55X72X5.8-MM THK) | |
| 8. | 371-1923J | [1] | CAP-DUST | |
| 9. | 376-6648J | [1] | BEARING-TAPERED ROLLER | |
| 10. | 371-2033J | [2] | PLUG | |
| 11. | 371-2034J | [1] | PLUG-MAGNETIC(AUGER CONVEYOR) | |
| 12. | 396-8318J | [1] | SEAL-LIP TYPE | |
| 13. | 298-6953J | [1] | BEARING AS | |
| 14. | 368-8584J | [1] | SPACER(42.5X49.5X3.5-MM THK) | |
| 15. | 368-8490J | [1] | NUT-SPANNER | |
| 16. | 362-1295H | [1] | SPACER(40X47X14.5-MM THK) | |
| | | | |
| | | | PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE NUMBER ARE NOT SERVICED SEPARATELY |
| | | | |
| | | | AVAILABLE REPLACEMENT PART(S): |
| | 361-3946H | [1] | KIT-GEAR | |
| | 361-3945J | [1] | KIT-HOUSING | |
| | H | | KIT MARKED H SERVICES PART(S) MARKED H |
| | J | | KIT MARKED J SERVICES PART(S) MARKED J |
| | M | | METRIC PART |
