卡特零件查询（AP655F） 397-4091: VALVE GP-FLOW DIVIDER
广数供应链运营团队, 17 02月, 2025，浏览：
527 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 436-6570 | [1] | VALVE GP-SOLENOID(FRONT WHL ASSIST, PRESS CNTRL) | |
| | 255-6257 | [1] | KIT-SEAL(CHECK VALVE) | |
| | | | (INCLUDES O-RINGS & BACKUP RING) |
| | 339-5305 | [1] | NUT(M16X1-THD) | |
| | 436-6572 | [1] | COIL-SOLENOID | |
| 2. | 373-1998 | [1] | VALVE AS-CHECK(FREE WHEEL ENGAGE) | |
| | 311-2134 | [1] | KIT-SEAL(CHECK VALVE) | |
| | | | (INCLUDES O-RING SEALS & BACKUP RINGS) |
| 3. | 436-7096 | [1] | VALVE GP-RELIEF(FREE WHEEL DISENGAGE) | |
| | 311-2134 | [1] | KIT-SEAL(CHECK VALVE) | |
| | | | (INCLUDES O-RING SEALS & BACKUP RINGS) |
| 4. | 436-6957 | [1] | VALVE GP-FLOW DIVIDER(FRONT WHEEL ASSIST) | |
| 5. | 436-6595 | [1] | VALVE GP-CONTROL(FRONT WHEEL ASSIST ON,OFF) | |
| | | | (EACH VALVE GP INCLUDES) |
| | 436-6956 | [1] | KIT-SEAL | |
| | | | (INCLUDES O-RINGS & BACKUP RINGS) |
