卡特零件查询（AP655F） 455-1573: SEAT GP-SUSPENSION
广数供应链运营团队, 17 02月, 2025，浏览：
939 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 242-8768 | [1] | COVER AS | |
| | 245-7895 | [1] | KIT-CLIP | |
| | | | (INCLUDES CLIPS) |
| 2. | 424-5304 | [1] | KIT-SPRING | |
| | | | (INCLUDES SCREWS, TAP, BAG, TIE WIRE, LOOMS, BRACKET AS & BOX) |
| 3. | 424-5302 | [1] | KIT-DAMPER | |
| | | | (INCLUDES LOCK WASHERS, PIN, BUSH, SPACER, BAG & BOX) |
| 4. | 424-5268 | [1] | KIT-COMPRESSOR | |
| | | | (INCLUDES CLIP, BAGS, LOOMS, LABEL, BRACKET AS, SCREWS, TAP, TIE WIRE & BOX)) |
| 5. | 209-4279 | [1] | BUMPER-STOP | |
| 6. | 424-5305 | [1] | KIT-VALVE | |
| | | | (INCLUDES KNOB, BRACKET, PIN, NUT, VALVES, PLUG, BAG & BOX) |
