卡特零件查询（AP655F） 395-0113: WIRING GP-ENGINE
广数供应链运营团队, 17 02月, 2025，浏览：
706 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 323-7347C | [3] | SEAL-O-RING | |
| 2. | 254-3633CM | [3] | BOLT-FLANGE HEAD(M6X1X16-MM, SELF LOCKING) | |
| 3. | 124-3815M | [4] | BOLT(M8X1.25X16-MM) | |
| 4. | 217-9039 | [1] | STRAP-CABLE | |
| 5. | 348-4637 | [1] | BOLT | |
| 6. | 458-3745C | [3] | HARNESS AS-PLATFORM | |
| | | | (EACH INCLUDES) |
| | 332-7865 | [1] | TIE-CABLE | |
| 7. | 377-1293 | [1] | BRACKET | |
| 8. | 385-5997Y | [1] | HARNESS AS-ENGINE | |
| 9. | 389-3863 | [1] | BRACKET | |
| 10. | 392-2780 | [1] | BRACKET | |
| 11. | 132-5789 | [1] | CLIP(LADDER) | |
| 12. | 232-1693M | [1] | BOLT-FLANGE HEAD(M6X1X35-MM) | |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
