卡特零件查询（AP655F） 490-5991: SUSPENSION GP-SEAT
广数供应链运营团队, 17 02月, 2025，浏览：
910 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 371-7147 | [1] | HANDLE | |
| 2. | 483-2910 | [1] | KIT-BOOT | |
| | | | (INCLUDES DUST COVER & RIVET) |
| 3. | 490-5992 | [1] | HOUSING GP-SEAT SUSPENSION | |
| | 483-2921 | [1] | GROMMET | |
| 4. | 490-5993 | [1] | KIT-TETHER BELT | |
| | 8T-0389M | [4] | LOCKNUT(M10X1.5-THD) | |
| | 095-0658M | [4] | BOLT-SOCKET HEAD(M10X1.5X70-MM) | |
| | 490-5975 | [2] | BELT-TETHER | |
| 5. | 490-5994 | [1] | KIT-SEAT | |
| | 475-5561 | [4] | SPACER | |
| 6. | 490-5995 | [1] | KIT-SEAT | |
| | | | (INCLUDES BELT, JACKET, LUG, ROLLER & SPRING) |
| 7. | 490-5996 | [1] | KIT-BUMPER | |
| | | | (INCLUDES BUMBER) |
| 8. | 490-5997 | [1] | KIT-DAMPER | |
| | | | (INCLUDES BOLT, DAMPER & WASHER) |
| 9. | 490-5998 | [4] | ROLLER | |
| 10. | 6V-8235 | [1] | PIN-SPRING | |
| | M | | METRIC PART |
