卡特零件查询（BG655D） 291-9138: HYDRAULIC AR
广数供应链运营团队, 17 02月, 2025，浏览：
635 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 270-7226Y | [1] | CYLINDER & MTG GP-AUGER | |
| | 270-7223Y | [1] | CYLINDER & MTG GP-HOPPER | |
| | 270-7224Y | [1] | CYLINDER & MTG GP-SCREED HOIST | |
| | 256-5327Y | [1] | CYLINDER & MTG GP-TENSIONER | |
| | 270-7227Y | [1] | CYLINDER & MTG GP-TOW POINT | |
| | 270-3543Y | [1] | LINES GP-BRAKE & SHIFT | |
| | 270-7233Y | [1] | LINES GP-CYLINDER | |
| | 270-7231Y | [1] | LINES GP-HOPPER | |
| | 270-3544Y | [1] | LINES GP-PUMP | |
| | 270-7244Y | [1] | LINES GP-RETURN | |
| | 270-7229Y | [1] | LINES GP-SCREED | |
| | 270-7246Y | [1] | LINES GP-SLOPE | |
| | 270-3542Y | [1] | LINES GP-TRACK TENSION | |
| | 270-7249Y | [1] | MANIFOLD GP-CONTROL | |
| | 270-7218Y | [1] | PUMP & MTG GP-AUXILIARY | |
| | 270-3530Y | [1] | VALVE & MTG GP-AUXILIARY(MAIN) | |
| | 270-7220Y | [1] | VALVE & MTG GP-AUXILIARY | |
| | 270-7219Y | [1] | VALVE & MTG GP-CONTROL | |
| | 270-7222Y | [1] | VALVE & MTG GP-COUNTERBALANCE(HOPPER HOIST, TOW POINT) | |
| | 270-3540Y | [1] | VALVE & MTG GP-TRACK TENSIONER | |
| | Y | | SEPARATE ILLUSTRATION |
