卡特零件查询（BG655D） 270-4253: DRIVE GP-PUMP
广数供应链运营团队, 17 02月, 2025，浏览：
953 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5E-9315 | [2] | FITTING-HOSE | |
| 2. | 5P-4961 | [2] | CLAMP-HOSE | |
| 3. | 235-3571 | [1] | ADAPTER AS | |
| | 3D-2824 | [1] | SEAL-O-RING | |
| | 6V-7483 | [1] | ADAPTER | |
| 4. | 240-3462 | [1] | COUPLING AS | |
| | 2H-3738 | [16] | BOLT(5/16-24X1-IN) | |
| | 3D-8752 | [16] | LOCKNUT(5/16-24-THD) | |
| 5. | | [1] | ADAPTER AS |
| | 260-9183 | [1] | ADAPTER | |
| | 3D-2824 | [1] | SEAL-O-RING | |
| 6. | 260-9185 | [1] | WASHER-COPPER(27X32X2-MM THK) | |
| 7. | 352-2524CY | [1] | DRIVE GP-HYDROSTATIC(PUMP) | |
| 8. | 270-0279 | [1] | BREATHER(PUMP DRIVE) | |
| 9. | 276-3503 | [1] | PIPE-THREADED | |
| 10. | 276-3504 | [1] | PIPE-THREADED | |
| 11. | 276-3505 | [1] | PLATE | |
| 12. | 283-4288 | [1] | SPACER(12X25X45-MM THK) | |
| 13. | 000-7246 | [1] | ELBOW | |
| 14. | 090-9019 | [1] | PLUG-PIPE | |
| 15. | 150-3028 | [1] | ELBOW AS | |
| | 3D-2824 | [1] | SEAL-O-RING | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 6V-9343 | [1] | ELBOW | |
| 16. | 165-4934 | [1] | PLUG AS | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 6V-9508 | [1] | PLUG(11/16-16-THD) | |
| 17. | 2R-7712 | [1] | COUPLING(REDUCING) | |
| 18. | 3B-7728 | [1] | ELBOW | |
| 19. | 3S-8664 | [1] | CLIP(LOOP) | |
| 20. | 7X-3183 | [8] | BOLT(3/8-24X1-IN) | |
| 21. | 7X-7729 | [3] | WASHER(11X25X3-MM THK) | |
| 22. | 8T-4121 | [2] | WASHER-HARD(11X21X2.5-MM THK) | |
| 23. | 8T-4133M | [1] | NUT(M10X1.5-THD) | |
| 24. | 8T-4136M | [2] | BOLT(M10X1.5X25-MM) | |
| 25. | 8T-4137M | [1] | BOLT(M10X1.5X20-MM) | |
| 26. | 8T-4195M | [12] | BOLT(M10X1.5X30-MM) | |
| 27. | 8T-4896 | [8] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 28. | 8T-5005M | [1] | BOLT(M10X1.5X70-MM) | |
| 29. | 9M-4972 | [1] | CLIP(LOOP) | |
| 30. | 5P-1442E | | HOSE(68-CM) | |
| 31. | 148-8312 | [2] | ADAPTER AS | |
| | | | (EACH INCLUDES) |
| | 3D-2824 | [1] | SEAL-O-RING | |
| | 3T-4965 | [1] | ADAPTER | |
| 32. | 8T-5095 | [12] | WASHER-PLATED(11X16X2-MM THK) | |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
