| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 310-5484 | [2] | TUBE | |
| 2. | 8T-8007 | [2] | SEGMENT-QUARTER AUGER | |
| 3. | 8T-8008 | [2] | SEGMENT-QUARTER AUGER | |
| 4. | 6V-7687M | [2] | LOCKNUT(M12X1.75-THD) | |
| 5. | 8T-4223 | [4] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 6. | 310-6460 | [2] | BOLT(M12X1.75X130-MM) | |
| QUANTITIES SHOWN ARE THOSE REQUIRED FOR BOTH LH & RH SIDES | ||||
| M | METRIC PART | |||
