卡特零件查询（10-20B） 8I-0143: VIBRATORY GP
广数供应链运营团队, 17 02月, 2025，浏览：
408 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8I-0144 | [2] | SHAFT AS-VIBRATORY | |
| 2. | 112-1276Y | [1] | SHAFT GP-DRIVE(ECCENTRIC WEIGHT) | |
| 3. | 102-2695 | [8] | BEARING | |
| 4. | 102-2690 | [4] | COUPLING | |
| 5. | 102-2739 | [4] | KEY-SQUARE | |
| 6. | 105-1533 | [4] | KEY-SQUARE | |
| 7. | 102-2735 | [2] | KEY-SQUARE | |
| 9. | 5P-2566 | [32] | BOLT(1/2-13X1.5-IN) | |
| 10. | 8T-4223 | [36] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 11. | 6V-8188 | [32] | NUT(1/2-13-THD) | |
| 12. | 5P-2228 | [4] | BOLT(1/2-13X1-IN) | |
| 13. | 205-7165 | [1] | COVER | |
| 14. | 205-7164 | [1] | COVER | |
| 15. | 8I-0145 | [2] | SHAFT AS-VIBRATORY | |
| 16. | 8I-0720 | [8] | CONNECTOR | |
| 17. | 148-8320 | [11] | CONNECTOR AS | |
| | | | (EACH INCLUDES) |
| | 4J-5477 | [1] | SEAL-O-RING | |
| | 8C-6865 | [1] | CONNECTOR | |
| 19. | 8I-0718I | [2] | HOSE AS | |
| 20. | 144-0360I | [2] | HOSE AS | |
| 21. | 5P-9982 | [5] | FITTING-GREASE | |
| 22. | 8J-1256 | [4] | CLIP(LOOP) | |
| 23. | 6V-8185 | [2] | NUT(1/4-20-THD) | |
| 24. | 8T-4205 | [6] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 25. | 7R-7906 | [4] | CLAMP | |
| 26. | 7V-5628 | [2] | PLATE(TOP) | |
| 27. | 4M-5282 | [4] | BOLT(1/4-20X1.5-IN) | |
| 28. | 9S-1812 | [1] | FITTING(NIPPLE-PIPE) | |
| 29. | 148-8351 | [3] | ELBOW AS | |
| | | | (EACH INCLUDES) |
| | 4J-5477 | [1] | SEAL-O-RING | |
| | 6V-9849 | [1] | ELBOW | |
| 30. | 8I-0967 | [1] | TUBE AS | |
| 31. | 8I-0968 | [1] | TUBE AS | |
| 32. | 8I-0969 | [1] | TUBE AS | |
| 33. | 148-8337 | [3] | CONNECTOR AS | |
| | | | (EACH INCLUDES) |
| | 4J-5477 | [1] | SEAL-O-RING | |
| | 8C-6866 | [1] | CONNECTOR | |
| 34. | 098-2599 | [3] | FITTING-GREASE | |
| 36. | 7C-4354 | [1] | CLIP | |
| 38. | 4D-0659 | [1] | BOSS | |
| 39. | 6V-8801 | [1] | NUT(3/8-16-THD) | |
| 40. | 8T-4896 | [2] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | Y | | SEPARATE ILLUSTRATION |
